PowerFlex® 700 and 700S Product Selection 1-5
(1) You must select (1) option from this group.
(2) All drives mounted in the same MCC vertical section must have option 111 if any one drive unit has option 111.
(3) You may select up to (1) option from this group.
(4) Pilot lights are Allen-Bradley® Bulletin 800M products and the pushbutton is an Allen-Bradley Bulletin 800T device.
(5) If one drive unit has base channels in any lineup, the entire lineup must have base channels. Base channels add 1.5 inches to the unit height.
(6) Option 6P is not available for drive units with voltage codes D, S, E, and F.
(7) Units with voltage codes D, S, E and F require horizontal power bus options. Only 800A, 1600A, and 3000A are available.
(8) You must select a ground bus option. If your lineup has a 3000A power bus, you must select the ground bus option for units with a 3000A-rated power bus.
(9) You must select a horizontal power bus option if you select a control bus.
(10) Units come standard with cloth wire labels. Datab labels offer the added protection of a clear plastic cover on top of the labels.
(11) Horizontal power bus is braced for 65kAIC.
(12) Maximum of 120 inches per shipping split.
(13) Requires an expended cassette for Phase II control.
(14) Available for Phase II control only. Requires an expanded cassette.
(15) For dual communications (DPI and DriveLogix) select the DriveLogix comm. option and order the DPI comm. kit separately.
(16) PowerFlex 700 frame 0 - 6 allows the “N” or “A” selections only. PowerFlex 700 frame 9 allows the “A” selection only. PowerFlex 700S frames 1 - 9 allows the “N” or “E” selections only.
(17) PowerFlex 700S only, requires an expanded cassette with Logix extras PCB.
(18) Required for PowerFlex 700S frames 1 - 6.
(19) Required for PowerFlex 700 frames 0 - 6 with voltages 380V AC, 460V AC, 575V AC, 512V DC, 620V DC, and 775V DC
(20) Required for PowerFlex 700 frames 0 - 2 with voltages 230V AC and 310 V DC
(21) You must select one (1) of these options for PowerFlex 700 frame 3 with voltages 230V AC and 310 V DC
(22) You must select one (1) of these options for PowerFlex 700S frame 9 with voltages 380V AC, 460V AC and 575V AC
(23) You must select one (1) of these options for PowerFlex 700S frame 9 with voltages 512V DC, 620V DC and 775V DC
Horizontal Power
Bus
(3)(7)(9)(11)(12)
08-AC 800A AC power bus
08-DC 800A DC power bus
12-AC 1200A AC power bus
16-AC 1600A AC power bus
16-DC 1600A DC power bus
20-AC 2000A AC power bus
30-AC 3000A AC power bus
30-DC 3000A DC power bus
Ground Bus (PE/
TE)
(1)(8)
XTEP2 PE/TE bus for unit with horizontal bus rated up to 2000A
XTEP3 PE/TE bus for unit with horizontal bus rated up to 3000A
115V AC Control
Bus
(9)
X115 90A control bus
Top Hat 12 inch high top hat for extra entry cable bending radius
Options Available to All Units:
Option Option Code Description
To Next Page
