Rockwell Automation Publication 750-IN020D-EN-P - May 2017 31
PowerFlex 755 IP00, NEMA/UL Open Type Drive
Figure 13 - Overall Dimensions with Mounting and Termination Kits – Frame 8 Common DC Input
0.0 (0.00)
1228.3 (48.36)
1100.0 (43.31)
953.1 (37.52)
788.0 (31.02)
623.0 (24.53)
0.0 (0.00)
119.2 (4.69)
236.0 (9.29)
466.0 (18.35)
1619.8 (63.77)
1978.8 (77.91)
420.5
(16.56)
93.9
(3.70)
309.9
(12.20)
2035.2
(80.13)
2111.8
(83.14)
777.9
(30.63)
Dimensions are in millimeters and (inches)
Front View
Right Side View
Shown without
Outlet Ducting Kit
5 mm Hex Key (Allen) - 10 places
11.3 N•m (100 lb•in)
5.0 mm (0.2 in.) - 4 places
11.3 N•m (100 lb•in)
