Allen-Bradley PowerFlex 755 IP00 User Manual

12 Rockwell Automation Publication 750-IN020D-EN-P - May 2017
PowerFlex 755 IP00, NEMA/UL Open Type Drive
Common DC Input Drives
Drive Ratings
The following tables provide rating and selection information for the common
DC input PowerFlex 755 IP00 NEMA/UL Open Type drives.
540V DC, 50 Hz Input
Three-Phase, 0…400 Hz Output
650V DC, 60 Hz Input
Three-Phase, 0…400 Hz Output
Light Duty Normal Duty Heavy Duty
Input Voltage
Range
Base Drive
Catalog Number
Quantity
Required
Equivalent
Frame Size
Input
Amps
Output Amps
kW
Input
Amps
Output Amps
kW
Input
Amps
Output Amps
kWCont. 1 min 3 s Cont. 1 min 3 s Cont. 1 min 3 s V DC
621 540 594 NA 315 529 460 506 693 250 443 385 578 693 200 486…594 20G14TC460 1 8
673 585 644 315 621 540 594 821 315 525 456 684 821 250 486…594 20G14TC540 1 8
704 612 673 355 652 567 624 851 315 543 472 708 851 250 486…594 20G14TC567 1 8
863 750 825 400 748 650 715 975 355 621 540 810 975 315 486…594 20G14TC650 1 8
916 796 876 450 863 750 825 1125 400 673 585 878 1125 315 486…594 20G14TC750 1 8
957 832 915 450 886 770 847 1155 400 739 642 963 1155 355 486…594 20G14TC770 1 8
1197 1040 1144 560 1047 910 1001 1365 500 863 750 1125 1365 400 486…594 20G14TC460 2 9
1254 1090 1199 630 1197 1040 1144 1584 560 1013 880 1320 1584 500 486…594 20G14TC540 2 9
1352 1175 1293 710 1254 1090 1199 1638 630 1047 910 1365 1638 500 486…594 20G14TC567 2 9
1686 1465 1612 800 1352 1175 1293 1872 710 1197 1040 1560 1872 560 486…594 20G14TC650 2 9
1703 1480 1628 850 1686 1465 1612 2198 800 1254 1090 1635 2198 630 486…594 20G14TC750 2 9
1841 1600 1760 900 1703 1480 1628 2220 850 1352 1175 1763 2220 710 486…594 20G14TC770 2 9
1974 1715 1887 1000 1830 1590 1749 2385 900 1525 1325 1988 2385 710 486…594 20G14TC567 3 10
2681 2330 2563 1400 2474 2150 2365 3225 1250 2071 1800 2700 3225 1000 486…594 20G14TC770 3 10
Light Duty Normal Duty Heavy Duty
Input Voltage
Range
Base Drive
Catalog Number
Quantity
Required
Equivalent
Frame Size
Input
Amps
Output Amps
Hp
Input
Amps
Output Amps
Hp
Input
Amps
Output Amps
HpCont. 1 min 3 s Cont. 1 min 3 s Cont. 1 min 3 s V DC
533 485 534 NA 400 473 430 473 666 350 407 370 555 666 300 585…715 20G14TD430 1 8
599 545 600 450 533 485 534 745 400 455 414 621 745 350 585…715 20G14TD485 1 8
649 590 649 500 599 545 600 818 450 499 454 681 818 350 585…715 20G14TD545 1 8
781 710 781 600 678 617 679 926 500 533 485 728 926 400 585…715 20G14TD617 1 8
841 765 842 650 781 710 781 1065 600 599 545 818 1065 450 585…715 20G14TD710 1 8
880 800 880 700 814 740 817 1110 650 678 617 926 1110 500 585…715 20G14TD740 1 8
1055 960 1056 800 880 800 880 1278 700 781 710 1065 1278 600 585…715 20G14TD430 2 9
1149 1045 1150 900 1055 960 1056 1440 800 874 795 1193 1440 700 585…715 20G14TD485 2 9
1248 1135 1249 1000 1149 1045 1150 1568 900 880 800 1200 1568 750 585…715 20G14TD545 2 9
1501 1365 1502 1100 1248 1135 1249 1728 1000 1055 960 1440 1728 800 585…715 20G14TD617 2 9
1561 1420 1562 1250 1501 1365 1502 2048 1100 1149 1045 1568 2048 900 585…715 20G14TD710 2 9
1693 1540 1694 1350 1561 1420 1562 2130 1250 1248 1135 1703 2130 1000 585…715 20G14TD740 2 9
1819 1655 1821 1500 1677 1525 1678 2288 1350 1396 1270 1905 2288 1100 585…715 20G14TD545 3 10
2463 2240 2464 2000 2276 2070 2277 3105 1750 1902 1730 2595 3105 1650 585…715 20G14TD740 3 10
