Allen-Bradley PowerFlex 755 IP00 User Manual

Rockwell Automation Publication 750-IN020D-EN-P - May 2017 13
PowerFlex 755 IP00, NEMA/UL Open Type Drive
810V DC, 60 Hz Input
Three-Phase, 0…400 Hz Output
932V DC, 50 Hz Input
Three-Phase, 0…400 Hz Output
Light Duty Normal Duty Heavy Duty
Input Voltage
Range
Base Drive
Catalog Number
Quantity
Required
Equivalent
Frame Size
Input
Amps
Output Amps
Hp
Input
Amps
Output Amps
Hp
Input
Amps
Output Amps
HpCont. 1 min 3 s Cont. 1 min 3 s Cont. 1 min 3 s V DC
391 355 391 NA 350 325 295 325 490 300 300 272 408 490 250 729…891 20G14TE295 1 8
436 395 435 400 391 355 391 533 350 325 295 443 533 300 729…891 20G14TE355 1 8
480 435 479 450 436 395 435 593 400 363 329 494 593 350 729…891 20G14TE395 1 8
507 460 506 500 480 435 479 639 450 391 355 533 639 350 729…891 20G14TE435 1 8
562 510 561 500 507 460 506 711 500 436 395 593 711 400 729…891 20G14TE460 1 8
601 545 600 550 562 510 561 765 500 469 425 638 765 450 729…891 20G14TE510 1 8
761 690 759 700 656 595 655 918 600 562 510 765 918 500 729…891 20G14TE295 2 9
838 760 836 800 695 630 693 1071 700 656 595 893 1071 600 729…891 20G14TE355 2 9
921 835 919 900 838 760 836 1140 800 695 630 945 1140 700 729…891 20G14TE395 2 9
993 900 990 950 910 825 908 1260 900 772 700 1050 1260 750 729…891 20G14TE435 2 9
1081 980 1078 1000 993 900 990 1368 950 838 760 1140 1368 800 729…891 20G14TE460 2 9
1152 1045 1150 1100 1081 980 1078 1470 1000 899 815 1223 1470 900 729…891 20G14TE510 2 9
1345 1220 1342 1200 1224 1110 1221 1665 1100 1015 920 1380 1665 1000 729…891 20G14TE395 3 10
1687 1530 1683 1500 1577 1430 1573 2145 1400 1312 1190 1785 2145 1250 729…891 20G14TE510 3 10
Light Duty Normal Duty Heavy Duty
Input Voltage
Range
Base Drive
Catalog Number
Quantity
Required
Equivalent
Frame Size
Input
Amps
Output Amps
kW
Input
Amps
Output Amps
kW
Input
Amps
Output Amps
kWCont. 1 min 3 s Cont. 1 min 3 s Cont. 1 min 3 s V DC
363 330 363 NA 315 292 265 292 375 250 237 215 323 375 200 839…1025 20G14TF265 1 8
407 370 407 355 363 330 363 473 315 292 265 398 473 250 839…1025 20G14TF330 1 8
451 410 451 400 407 370 407 555 355 339 308 462 555 300 839…1025 20G14TF370 1 8
506 460 506 450 457 415 457 639 400 407 370 555 639 355 839…1025 20G14TF415 1 8
550 500 550 500 506 460 506 675 450 413 375 563 675 375 839…1025 20G14TF460 1 8
583 530 583 530 550 500 550 750 500 454 413 620 750 400 839…1025 20G14TF500 1 8
715 650 715 630 649 590 649 885 560 506 460 690 885 450 839…1025 20G14TF265 2 9
781 710 781 710 715 650 715 975 630 550 500 750 975 500 839…1025 20G14TF330 2 9
869 790 869 800 781 710 781 1065 710 649 590 885 1065 560 839…1025 20G14TF370 2 9
946 860 946 850 842 765 842 1170 750 715 650 975 1170 630 839…1025 20G14TF415 2 9
1056 960 1056 900 875 795 875 1350 800 825 750 1125 1350 710 839…1025 20G14TF460 2 9
1122 1020 1122 1000 1056 960 1056 1440 900 875 795 1193 1440 800 839…1025 20G14TF500 2 9
1265 1150 1265 1100 1144 1040 1144 1560 1000 952 865 1298 1560 900 839…1025 20G14TF370 3 10
1634 1485 1634 1500 1540 1400 1540 2100 1400 1276 1160 1740 2100 1120 839…1025 20G14TF500 3 10
