8 Rockwell Automation Publication 750-IN020D-EN-P - May 2017
PowerFlex 755 IP00, NEMA/UL Open Type Drive
AC Input Drives
Drive Ratings
The following tables provide rating and selection information for the PowerFlex
755 IP00 NEMA/UL Open Type AC input drives.
380…480V AC, Three-Phase, 50 Hz Input
Three-Phase, 0…400 Hz Output
480V AC, Three-Phase, 60 Hz Input
Three-Phase, 0…400 Hz Output
Light Duty Normal Duty Heavy Duty
Input Voltage
Range
Base Drive
Catalog Number
Quantity
Required
Equivalent
Frame Size
Input
Amps
Output Amps
kW
Input
Amps
Output Amps
kW
Input
Amps
Output Amps
kWCont. 1 min 3 s Cont. 1 min 3 s Cont. 1 min 3 s V AC
534 540 594 NA 315 455 460 506 693 250 380 385 578 693 200 360…440 20G11TC460 1 8
578 585 644 315 533 540 594 821 315 450 456 684 821 250 360…440 20G11TC540 1 8
604 612 673 355 560 567 624 851 315 466 472 708 851 250 360…440 20G11TC567 1 8
739 750 825 400 640 650 715 975 355 533 540 810 975 315 360…440 20G11TC650 1 8
784 796 876 450 739 750 825 1125 400 577 585 878 1125 315 360…440 20G11TC750 1 8
819 832 915 450 758 770 847 1155 400 634 642 963 1155 355 360…440 20G11TC770 1 8
1024 1040 1144 560 896 910 1001 1365 500 739 750 1125 1365 400 360…440 20G11TC460 2 9
1073 1090 1199 630 1024 1040 1144 1584 560 867 880 1320 1584 500 360…440 20G11TC540 2 9
1157 1175 1293 710 1073 1090 1199 1638 630 896 910 1365 1638 500 360…440 20G11TC567 2 9
1443 1465 1612 800 1157 1175 1293 1872 710 1024 1040 1560 1872 560 360…440 20G11TC650 2 9
1457 1480 1628 850 1443 1465 1612 2198 800 1073 1090 1635 2198 630 360…440 20G11TC750 2 9
1576 1600 1760 900 1457 1480 1628 2220 850 1157 1175 1763 2220 710 360…440 20G11TC770 2 9
1689 1715 1887 1000 1566 1590 1749 2385 900 1305 1325 1988 2385 710 360…440 20G11TC567 3 10
2294 2330 2563 1400 2117 2150 2365 3225 1250 1773 1800 2700 3225 1000 360…440 20G11TC770 3 10
Light Duty Normal Duty Heavy Duty
Input Voltage
Range
Base Drive
Catalog Number
Quantity
Required
Equivalent
Frame Size
Input
Amps
Output Amps
Hp
Input
Amps
Output Amps
Hp
Input
Amps
Output Amps
HpCont. 1 min 3 s Cont. 1 min 3 s Cont. 1 min 3 s V AC
458 485 534 NA 400 406 430 473 666 350 349 370 555 666 300 432…528 20G11TD430 1 8
514 545 600 450 458 485 534 745 400 391 414 621 745 350 432…528 20G11TD485 1 8
557 590 649 500 514 545 600 818 450 428 454 681 818 350 432…528 20G11TD545 1 8
670 710 781 600 582 617 679 926 500 458 485 728 926 400 432…528 20G11TD617 1 8
722 765 842 650 670 710 781 1065 600 514 545 818 1065 450 432…528 20G11TD710 1 8
755 800 880 700 698 740 817 1110 650 582 617 926 1110 500 432…528 20G11TD740 1 8
906 960 1056 800 755 800 880 1278 700 670 710 1065 1278 600 432…528 20G11TD430 2 9
986 1045 1150 900 906 960 1056 1440 800 750 795 1193 1440 700 432…528 20G11TD485 2 9
1071 1135 1249 1000 986 1045 1150 1568 900 755 800 1200 1568 750 432…528 20G11TD545 2 9
1288 1365 1502 1100 1071 1135 1249 1728 1000 906 960 1440 1728 800 432…528 20G11TD617 2 9
1340 1420 1562 1250 1288 1365 1502 2048 1100 986 1045 1568 2048 900 432…528 20G11TD710 2 9
1453 1540 1694 1350 1340 1420 1562 2130 1250 1071 1135 1703 2130 1000 432…528 20G11TD740 2 9
1562 1655 1821 1500 1439 1525 1678 2288 1350 1199 1270 1905 2288 1100 432…528 20G11TD545 3 10
2114 2240 2464 2000 1953 2070 2277 3105 1750 1633 1730 2595 3105 1650 432…528 20G11TD740 3 10
