Allen-Bradley PowerFlex 755 IP00 User Manual

Rockwell Automation Publication 750-IN020D-EN-P - May 2017 9
PowerFlex 755 IP00, NEMA/UL Open Type Drive
600V AC, Three-Phase, 60 Hz Input
Three-Phase, 0…400 Hz Output
690V AC, Three-Phase, 50 Hz Input
Three-Phase, 0…400 Hz Output
Light Duty Normal Duty Heavy Duty
Input Voltage
Range
Base Drive
Catalog Number
Quantity
Required
Equivalent
Frame Size
Input
Amps
Output Amps
Hp
Input
Amps
Output Amps
Hp
Input
Amps
Output Amps
HpCont. 1 min 3 s Cont. 1 min 3 s Cont. 1 min 3 s V AC
335 355 391 NA 350 278 295 325 490 300 257 272 408 490 250 540…660 20G11TE295 1 8
373 395 435 400 335 355 391 533 350 278 295 443 533 300 540…660 20G11TE355 1 8
411 435 479 450 373 395 435 593 400 310 329 494 593 350 540…660 20G11TE395 1 8
434 460 506 500 411 435 479 639 450 335 355 533 639 350 540…660 20G11TE435 1 8
481 510 561 500 434 460 506 711 500 373 395 593 711 400 540…660 20G11TE460 1 8
514 545 600 550 481 510 561 765 500 401 425 638 765 450 540…660 20G11TE510 1 8
651 690 759 700 562 595 655 918 600 481 510 765 918 500 540…660 20G11TE295 2 9
717 760 836 800 595 630 693 1071 700 562 595 893 1071 600 540…660 20G11TE355 2 9
788 835 919 900 717 760 836 1140 800 595 630 945 1140 700 540…660 20G11TE395 2 9
849 900 990 950 779 825 908 1260 900 661 700 1050 1260 750 540…660 20G11TE435 2 9
925 980 1078 1000 849 900 990 1368 950 717 760 1140 1368 800 540…660 20G11TE460 2 9
986 1045 1150 1100 925 980 1078 1470 1000 769 815 1223 1470 900 540…660 20G11TE510 2 9
1151 1220 1342 1200 1048 1110 1221 1665 1100 868 920 1380 1665 1000 540…660 20G11TE395 3 10
1444 1530 1683 1500 1350 1430 1573 2145 1400 1123 1190 1785 2145 1250 540…660 20G11TE510 3 10
Light Duty Normal Duty Heavy Duty
Input Voltage
Range
Base Drive
Catalog Number
Quantity
Required
Equivalent
Frame Size
Input
Amps
Output Amps
kW
Input
Amps
Output Amps
kW
Input
Amps
Output Amps
kWCont. 1 min 3 s Cont. 1 min 3 s Cont. 1 min 3 s V AC
311 330 363 NA 315 250 265 292 375 250 203 215 323 375 200 621…759 20G11TF265 1 8
349 370 407 355 311 330 363 473 315 250 265 398 473 250 621…759 20G11TF330 1 8
386 410 451 400 349 370 407 555 355 290 308 462 555 300 621…759 20G11TF370 1 8
433 460 506 450 391 415 457 639 400 349 370 555 639 355 621…759 20G11TF415 1 8
471 500 550 500 433 460 506 675 450 353 375 563 675 375 621…759 20G11TF460 1 8
499 530 583 530 471 500 550 750 500 389 413 620 750 400 621…759 20G11TF500 1 8
612 650 715 630 556 590 649 885 560 433 460 690 885 450 621…759 20G11TF265 2 9
669 710 781 710 612 650 715 975 630 471 500 750 975 500 621…759 20G11TF330 2 9
744 790 869 800 669 710 781 1065 710 556 590 885 1065 560 621…759 20G11TF370 2 9
810 860 946 850 721 765 842 1170 750 612 650 975 1170 630 621…759 20G11TF415 2 9
904 960 1056 900 749 795 875 1350 800 706 750 1125 1350 710 621…759 20G11TF460 2 9
961 1020 1122 1000 904 960 1056 1440 900 749 795 1193 1440 800 621…759 20G11TF500 2 9
1083 1150 1265 1100 980 1040 1144 1560 1000 815 865 1298 1560 900 621…759 20G11TF370 3 10
1399 1485 1634 1500 1319 1400 1540 2100 1400 1093 1160 1740 2100 1120 621…759 20G11TF500 3 10
