Position
1…345678…10 11 12 13 14 15 16 17 18
20G 1 1 T D 485 A N 0 N NNNN
a b c d e f1…f2 g h
a
Drive
Code Type
20G PowerFlex 755
b
Future Use
c
Input Type
Code Description
1 AC Input w/Precharge
4 DC Input w/Precharge
d
Enclosure
Code Description
T IP00, UL Open Type without Control POD
e
Voltage Rating
Code Voltage
C 400V AC / 540V DC
D 480V AC / 650V DC
E 600V AC / 810V DC
F 690V AC / 932V DC (not UL listed)
f1
ND Rating
400V AC / 540V DC, 50 Hz Input
Code
Amps
kW
Quantity
Required
Equivalent
Frame Size
C460 460 250 1
8
C540 540 315 1
C567 567 315 1
C650 650 355 1
C750 750 400 1
C770 770 400 1
C460 910 500 2
9
C540 1040 560 2
C567 1090 630 2
C650 1175 710 2
C750 1465 800 2
C770 1480 850 2
C567 1590 900 3
10
C770 2150 1250 3
To achieve the extended ratings listed for Frames 9 and 10, the base
Frame 8 drive must be paralleled 2 or 3 times. Refer to the Drive
Rating tables on pages 8, 9, 12, and 13 for detailed information.
f2
ND Rating
480V AC / 650V DC, 60 Hz Input
Code
Amps
Hp
Quantity
Required
Equivalent
Frame Size
D430 430 350 1
8
D485 485 400 1
D545 545 450 1
D617 617 500 1
D710 710 600 1
D740 740 650 1
D430 800 700 2
9
D485 960 800 2
D545 1045 900 2
D617 1135 1000 2
D710 1365 1100 2
D740 1420 1250 2
D545 1525 1350 3
10
D740 2070 1750 3
To achieve the extended ratings listed for Frames 9 and 10, the base
Frame 8 drive must be paralleled 2 or 3 times. Refer to the Drive
Rating tables on pages 8, 9, 12, and 13 for detailed information.
f3
ND Rating
600V AC / 810V DC, 60 Hz Input
Code
Amps
Hp
Quantity
Required
Equivalent
Frame Size
E295 295 300 1
8
E355 355 350 1
E395 395 400 1
E435 435 450 1
E460 460 500 1
E510 510 500 1
E295 595 600 2
9
E355 630 700 2
E395 760 800 2
E435 825 900 2
E460 900 950 2
E510 980 1000 2
E395 1110 1100 3
10
E510 1430 1400 3
To achieve the extended ratings listed for Frames 9 and 10, the base
Frame 8 drive must be paralleled 2 or 3 times. Refer to the Drive
Rating tables on pages 8, 9, 12, and 13 for detailed information.
f4
ND Rating
690V AC / 932V DC, 60 Hz Input (not UL listed)
Code
Amps
kW
Quantity
Required
Equivalent
Frame Size
F265 265 250 1
8
F330 330 315 1
F370 370 355 1
F415 415 400 1
F460 460 450 1
F500 500 500 1
F265 590 560 2
9
F330 650 630 2
F370 710 710 2
F415 765 750 2
F460 795 800 2
F500 960 900 2
F370 1040 1000 3
10
F500 1400 1400 3
To achieve the extended ratings listed for Frames 9 and 10, the base
Frame 8 drive must be paralleled 2 or 3 times. Refer to the Drive
Rating tables on pages 8, 9, 12, and 13 for detailed information.
g
Filtering and CM Cap Conguration
Code Filtering Default CM Cap Connection
A Yes Jumper Removed
J Yes Jumper Installed
h
Dynamic Braking §
Code Internal Resistor Internal Transistor
NNo No
§ Not available on Frames 8…10.
