Rockwell Automation Publication 750-IN020D-EN-P - May 2017 75
PowerFlex 755 IP00, NEMA/UL Open Type Drive
690 Volt AC Input (continued) 932V DC Input
800 kW 9 795 Heavy 20G11TF960 2 1193 1440 749 900 1000 950 475 1700 950 475 2200 2200 950 1000
795 Normal 20G11TF460 2 875 1350 749 900 1000 950 475 1700 950 475 2200 2200 950 1000 790 Light 20G11TF370 2 869 – 744 900 1000 950 475 1700 950 475 2200 2200 950 1000
850 kW 9 860 Light 20G11TF415 2 946 – 810 900 1000 1000 500 1800 1000 500 2400 2400 1000 1000
900 kW 9 960 Normal 20G11TF960 2 1056 1440 904 900 1000 1150 575 2000 1150 575 2700 2700 1150 1000
960 Light 20G11TF460 2 1056 – 904 900 1000 1150 575 2000 1150 575 2700 2700 1150 1000
10 865 Heavy 20G11TF370 3 1298 1560 815 900 1000 1000 500 1800 1000 500 2400 2400 1000 1000
1000 kW 9 1020 Light 20G11TF460 2 1122 – 961 900 1000 1200 600 2200 1200 600 2900 2900 1200 1000
10 1040 Normal 20G11TF370 3 1144 1560 980 900 1000 1250 625 2200 1250 625 2900 2900 1250 1000
1100 kW 10 1150 Light 20G11TF370 3 1265 1380 1083 900 1000 1350 675 2400 1350 675 3200 3200 1350 1000
1120 kW 10 1160 Heavy 20G11TF500 3 1740 2100 1093 900 1000 1350 675 2500 1350 675 3300 3300 1350 1000
1400 kW 10 1400 Normal 20G11TF500 3 1540 2100 1319 900 1000 1650 825 3000 1650 825 4000 4000 1650 1000 1500 kW 10 1485 Light 20G11TF500 3 1634 1782 1399 900 1000 1750 875 3100 1750 875 4200 4200 1750 1000
(1) “Applied Rating” refers to the motor that will be connected to the drive. For example, a “F400” drive can be used in Normal Duty mode on a 400 kW motor, in Heavy Duty mode on a 355 kW motor or in Light Duty mode on a 450 kW motor. The drive can be programmed
for each mode. Wiring and fuses can be sized based on the programmed mode. For any given drive catalog number, Normal Duty mode provides higher continuous current but smaller overload current with respect to Heavy Duty mode. See parameter 306 [Duty Rating]. See Specifications for an explanation of Duty Ratings.
(2) These AC line fuses (with blown fuse indicators) are included in the drive to provide drive short circuit protection. AC input protection devices for branch circuit protection based on US NEC are listed in the table. Each drive bay has one fuse per phase. (3) Minimum protection device size is the lowest rated device that supplies maximum protection without nuisance tripping. (4) Maximum protection device size is the highest rated device that supplies drive protection. For US NEC, minimum size is 125% of motor FLA. Ratings shown are maximum. (5) Circuit Breaker - inverse time breaker. For US NEC, minimum size is 125% of motor FLA. Ratings shown are maximum. (6) Recommended Motor circuit protector - Instantaneous trip circuit breaker. The trip setting should be set to the input current of the drive and should be sized for the continuous current of the system.
(7) These DC line fuses (with blown fuse indicators) are included in the drive to provide drive short circuit protection.
Applied Rating
(1)
Equiv. Frame
Cont. Output Amps Duty
Catalog Number
Quantity
Output Overload Amps
Continuous AC Input
AC Input Integral Semiconductor Fuse Size (170M)
(2)
DC Bay to Bay Integral Semiconductor Fuse Size (170M6648)
AC Input Protection Devices Recommended for Branch Circuit Protection
DC Input Integral Semiconductor Fuse Size (170M6253)
(7)
Dual Element Time Delay Fuse Non-Time Delay Fuse
Circuit Breaker Max Size
(5)
Motor Circuit Protector
(6)
1 min 3 s Amps Amps Amps
1/Phase Min
(3)
2/Phase Min
(3)
Max
(4)
1/Phase Min
(3)
2/Phase Min
(3)
Max
(4)
Amps
