Reference Section
CLR Clear • Deletes an entire text string.
• Displays the Select Action pop-up box used to clear the selected fault, alarm or event, or the entire fault,
alarm or event queue.
DEL Delete Deletes a highlighted character.
EDIT Edit • Accesses a displayed parameter to edit.
• Accesses the Edit Process Display screen.
END End • Displays the end (least recent) fault, alarm or event in a queue
• Scrolls to the end line of data on the Device Version information screen.
ENTER Enter • Displays the next level of a selected menu item.
• Enters new values.
• Performs the intended action.
ESC Escape • Cancels port verification conflict pop-up bo
x du
ring procedure to resolve a conflict.
• Cancels the existing screen and returns to the previous screen.
•Cancels an entry.
• Cancels pop-up Fault Display screen.
• Displays the time zone groups list screen (only when the Date/Time Set Edit Mode screen is shown).
EXP Exponent Allows data entry using scientific notation for 32-bit REAL (floating point) values.
FIX Fix Fixes ‘Changed’ or ‘Requires Configuration’ port verification conflicts upon powerup.
INFO Information • Shows additional information about a selected port verification conflict upon powerup.
• Shows additional information about Set Default actions.
INS Insert Inserts a space to the left of a highlighted character.
LINK Link Displays a Link Edit pop-up box to link pa
rameters (only PowerFlex 7-Class drives).
LOWER Lower Displays the lower 16 bits (bits 0…15) of a 32-bit Bit-type parameter.
MOST Most Restores most Host or Port device parameters to factory defaults.
PAR# Parameter Number Navigates directly to a parameter.
PGDN Page Down Scrolls down to the next page of da
ta
lines on the Device Version information screen.
PGUP Page Up Scrolls up to the previous page of data lines on the Device Version information screen.
REF Reference Enters the speed reference for the Host Drive.
RESET Reset Resets the Process screen’s displayed monitoring items to the factory default monitoring items.
TEXT Tex t Edits user-definable text for the device selected.
TOP Top • Displays the top (most recent) fault, alarm or event in a queue.
• Scrolls to the top line of data on the Device Version information screen.
UPPER Upper Displays the upper 16 bits (bits 16…31) of a 32-bit Bit-type parameter.
VIEW View • Toggles between select screens and views.
• Displays the time stamp screen from a fault, alarm or event queue screen.
ZONES Zones Displays the Select Time Zone screen.
Table 5 - Soft Key Label Explanation (Continued)
Soft Key Label Name Function
