Publication 2711-UM014B-EN-P
Specifications A-3
Character Sizes (Pixel size = 0.48 x 0.48 mm)
Terminal Memory
Total Application Flash Memory 240K bytes (application screens)
Environment
Operating Temperature 0 to 55° C (32 to 131° F)
Storage Temperature -25 to 85° C (-4 to 188° F)
Relative Humidity (non-condensing) 5 to 95% at 0 to 55° C (32 to 131° F)
Heat Dissipation 18 Watts (69 BTU/HR)
Impulse Shock (operating/non-operating) 15G/30G
Vibration (operating) 2G up to 2,000 Hz
Size in Pixels
width x height)
Characters/Row Maximum Rows Dimensions in mm
Width x Height
4 x 6 31 10 1.9 x 2.9
6 x 8 20 7 2.9 x 3.8
6 x 16 20 3 2.9 x 7.7
6 x 24 20 2 2.9 x 11.5
12 x 8 10 7 5.8 x 3.8
12 x 16 10 3 5.8 x 7.7
12 x 24 10 2 5.8 x 11.5
18 x 8 6 7 8.6 x 3.8
18 x 16 6 3 8.6 x 7.7
18 x 24 6 2 8.6 x 11.5
