A-4 Specifications
PanelView 550
Electrical
DC Power
Supply Voltage Limits
Power Consumption
Supply Voltage Limits (touch screen only)
Power Consumption (touch screen only)
18 to 30V dc (24V dc nominal)
18 Watts, max. (0.75A @ 24V dc)
18 to 32V dc (24V dc nominal)
18 Watts, max. (0.75A @ 24V dc)
AC Power
Supply Voltage Limits
Power Consumption
85 to 264V ac, 47 to 63 Hz
45 VA maximum
Mechanical
Enclosure NEMA Type 12/13, 4X (Indoor use only), IP54,
IP65
LED Indicators
COMM
Fault
Green
Red
Weight
Keypad, Keypad & Touch
Touch Screen
1.2 kg (2.7 lbs)
.93 kg (2.1 lbs)
Dimensions- Keypad, Keypad & Touch
mm
Inches
167 (H) x 266 (W) x 106 (D)
6.57 (H) x 10.47 (W) x 4.17 (D)
Dimensions- Touch Screen
mm
inches
152 (H) x 185 (W) x 82 (D)
6.00 (H) x 7.28 (W) x 3.20 (D)
Installed Depth- Keypad, Keypad & Touch 86 mm (3.39 inches)
118 mm (4.64 inches) with memory card retainer
207 mm (8.15 inches) with memory card retainer
and clearance to insert and remove memory card
Installed Depth- Touch Screen 64 mm (2.54 inches)
109 mm (4.30 inches) with memory card retainer
188 mm (7.40 inches) with memory card retainer
and clearance to insert and remove memory card
Display
Type Liquid Crystal Display (LCD)
Size 120 x 60 mm (4.75 x 2.38 in.)
Pixels 256 x 128
Touch Cells 128 (16 columns x 8 rows)
Touch Cell Size 16 x 16 pixels
Terminal Memory
PV550 ( Series E or later) or
PV550T (Series A or later)
Total Application Flash Memory
240K bytes (application screens)
PV550 (Prior to Series E)
Total Application Flash Memory
112K bytes (application screens)
