Publication 2711-UM014B-EN-P
A-6 Specifications
PanelView 600 Color
Keypad & Touch
Electrical
DC Power
Supply Voltage Limits
Power Consumption
85 to 264V ac, 43 to 63 Hz
60 VA maximum
AC Power
Supply Voltage Limits
Power Consumption
18 to 32V dc (24V dc nominal)
34 Watts max. (1.4A @ 24V dc)
Mechanical
Enclosure NEMA Type 12/13, 4X (Indoor use only), IP54,
IP65
LED Indicators
COMM
Fault
Green
Red
Weight 2 kg (4.4 lbs)
Dimensionsmm
mm
inches
192 (H) x 290 (W) x 116 (D)
7.55 (H) x 11.40 (W) x 4.57 (D)
Installed Depth 99 mm (3.89 inches)
131 mm (5.14 inches) with memory card retainer
220 mm (8.65 inches) with memory card retainer
and clearance to insert and remove memory card
Display
Type Active Matrix Thin-Film Resistor (TFT) with Cold
Cathode Fluorescent (CCF) Backlight
Size 115 x 86 mm (4.54 x 3.4 in.)
Pixels 320 x 234
Touch Cells 128 (16 columns x 8 rows)
Touch Cell Size 20 x 29 pixels
Terminal Memory
Total Application Flash Memory 240K bytes (application screens)
Environment
Operating Temperature 0 to 55° C (32 to 131° F)
Storage Temperature -25 to 70° C (-13 to 158° F)
Relative Humidity (non-condensing) 5 to 95% at 0 to 55° C (32 to 131° F)
Heat Dissipation 32 Watts (107 BTU/HR) for AC or DC Power
Impulse Shock (operating/non-operating) 30G/50G
Vibration (operating) 2G up to 2,000 Hz
