Allen-Bradley PV550 User Manual

Publication 2711-UM014B-EN-P
Specifications A-7
Character Sizes (Pixel size = 0.36 x 0.37 mm)
PanelView 600 Color
Touch Only
Size in Pixels
width x height)
Characters/Row Maximum Rows Dimensions in mm
Width x Height
6 x 9 52 25 2.9 x 5.9
8 x 16 39 14 2.9 x 5.9
8 x 24 39 9 2.9 x 8.9
16 x 24 19 9 5.8 x 8.9
24 x 32 13 7 8.6 x 11.8
32x 40 9 5 11.5 x 14.8
Electrical
DC Power
Supply Voltage Limits
Power Consumption
18 to 32V dc (24V dc nominal)
17 Watts max. (0.71A @ 24V dc)
Mechanical
Enclosure NEMA Type 12/13, 4X (Indoor use only), IP54,
IP65
LED Indicators
COMM
Fault
Green
Red
Weight 1 kg (2.3 lbs)
Dimensions
mm
Inches
152 (H) x 185 (W) x 96 (D)
6.00 (H) x 7.28 (W) x 3.80 (D)
Installed Depth 79 mm (3.12 inches)
132 mm (5.21 inches) with memory card retainer
211 mm (8.30 inches) with memory card retainer
and clearance to insert and remove memory card
Display
Type Passive Matrix LCD with Cold Cathode
Fluorescent (CCF) Backlight
Size 115 x 87 mm (4.54 x 3.43 in.)
Pixels 320 x 240
Touch Cells 128 (16 columns x 8 rows)
Touch Cell Size 20 x 30 pixels
Terminal Memory
Total Application Flash Memory 240K bytes (application screens)
