Publication 2711-UM014B-EN-P
A-8 Specifications
Character Sizes (Pixel size = 0.35 x 0.35 mm)
Environment
Operating Temperature 0 to 50° C (32 to 122° F)
Storage Temperature -25 to 70° C (-13 to 158° F)
Relative Humidity (non-condensing) 5 to 95% at 0 to 40° C (32 to 104° F)
Heat Dissipation 17 Watts (577 BTU/HR)
Impulse Shock (operating/non-operating) 15G/30G
Vibration (operating) 2G up to 2,000 Hz
Size in Pixels
width x height)
Characters/Row Maximum Rows Dimensions in mm
Width x Height
6 x 9 52 25 2.1 x 3.1
8 x 16 39 14 2.8 x 5.6
8 x 24 39 9 2.8 x 8.4
16 x 24 19 9 5.6 x 8.4
24 x 32 13 7 8.4 x 11.1
32x 40 9 5 11.1 x 13.9
