Rockwell Automation Publication 442L-UM005B-EN-P - April 2017 7
Preface
This user manual shows you how to mount, install, commission, operate, and
maintain your SafeZone Mini safety laser scanner correctly.
This user manual does not provide instructions for operating the machine,
system, or vehicle on which the safety laser scanner is, or will be, integrated.
This information can be found in the user manual for the machine, system, or
vehicle.
Summary of Changes
This manual contains new and updated information as indicated in the
following table.
Who Should Use This
Manual?
This user manual is intended for planning engineers, machine designers, and
the operators of machines and systems that are to be protected by one or several
SafeZone Mini devices. It is also for people that integrate SafeZone Mini
devices into a machine, system, or vehicle, initialize its use, or who are in charge
of servicing and maintaining the device.
Scope of Publication
This user manual is only applicable to the SafeZone Mini device with the
following entry on the type label in the field Operating Instructions (Part
Number 10000337275).
For the configuration and diagnostics of these devices, you require the Safety
Configuration and Diagnostic (SCD) software (version 3.0 or higher)
programming software. To determine the software version, select the Module
Info… option in the Help menu.
Depth of Information
This user manual contains information on the SafeZone Mini device in the
following parts:
IMPORTANT Read this Preface carefully before working with this documentation and the
SafeZone™ Mini safety laser scanner.
Topic Page
Updated Applications of the Device section. 12
Added Safe state in case of error to Table 23
.90
Added Safe state in case of error to Glossary. 101
• Mounting • Fault diagnosis and troubleshooting
• Electrical installation • Catalog numbers
• Commissioning and configuration • Accessories
• Care and maintenance • Conformity and approval
