Chapter 11 Technical Specifications
Dimensions
Table 19 - Dimensions [mm (in.)]
Functional Data
Table 20 - Functional Data
Attribute 442L-SFZNMN
SafeZone Mini Safety Laser Scanner
Height 116 (4.57)
Width 102 (4.02)
Depth 105 (4.13)
Total weight (without connecting cables) 0.8 kg (1.76 lb)
Connecting Cable
Length 250 (9.84)
Diameter of round plug connector 15 (0.59)
Attribute 442L-SFZNMN
Resolution of the 2 m (6.56 ft) SafeZone Mini Device 30, 40, 50, 70 mm (1.2, 1.6, 2.0, 2.8 in.)
Resolution of the 3 m (9.84 ft) SafeZone Mini Device 30, 40, 50, 70, 150 mm (1.2, 1.6, 2.0, 2.8, 5.9 in.)
Protective field of the 2 m (6.56 ft) SafeZone Mini Medium Range
At 30 mm (1.2 in.) resolution 1.25 m (4.10 ft)
At 40 mm (1.6 in.) resolution 1.60 m (5.25 ft)
At 50 mm (2.0 in.) resolution 2.00 m (6.56 ft)
At 70 mm (2.8 in.) resolution 2.00 m (6.56 ft)
Protective field of the 3 m (9.84 ft) SafeZone Mini Medium Range
At 30 mm (1.2 in.) resolution 1.25 m (4.10 ft)
At 40 mm (1.6 in.) resolution 1.60 m (5.25 ft)
At 50 mm (2.0 in.) resolution 2.10 m (6.89 ft)
At 70 mm (2.8 in.) resolution 3.00 m (9.84 ft)
At 150 mm (5.9 in.) resolution 3.00 m (9.84 ft)
Scan angle 270°
Remission 1.8% (min)
Several 1000% (reflectors) (max)
(3)
(3) Complies with Diamond Grade 3000X™ (approx. 1250 cd/lx × m²).
Angular resolution 0.5°
Protective field supplement necessary 100 mm (3.94 in.)
Supplement for retroreflectors in scan plane at a
distance of less than 1 m (39.4 in.) to the protective field
boundary
200 mm (7.87 in.)
Evenness of the scan field at 2 m (6.56 ft) ±50 mm (2.0 in.)
Distance from mirror axis of rotation (zero point on the X
and Y axis) to the rear of the device
55 mm (2.17 in.)
Distance between center of the scan plane and the
bottom edge of the housing
80 mm (3.15 in.)
Warning field
(1)
(1) The detection capability of the warning field is dependent on the remission of the objects to be detected.
8 m (26.25 ft)
Distance measuring range 30 m (98.4 ft)
Number of multiple samplings
(configurable via SCD software)
2…16
Power-up delay of a configured device 18 s
Restart after (configurable) 2…60 s
Basic response time
(2)
(2) The total response time of your application is dependent on further factors.
80 ms
