Addressing Reference
SLC 500 Family of Programmable Controllers
10
T
able F
Parameters
of Integer Elements
Description PLC Data Type Valid Range
Integer Element
signed word –32,768 thru +32,767
DB n
—
0 or 1
T
able G
Examples
for Integer Element 3 in the Default File (File 7)
To address the Use this form
Entire Element
$N7:3
Tenth Data Bit $N7:3/9
