Data Table Addressing for the SLC 500t
Family of Processors
This addressing reference helps you specify data table addresses in
SLC 500t fixed and modular programmable controllers. It contains
information for the following processors:
all SLC 500 Fixed Programmable Controllers
The following SLC 500 Modular Programmable Controllers
- SLC 5/01 CPU
- SLC 5/02 CPU
- SLC 5/03 CPU
Locating Addressing Information
For information about See page
memory maps
3
general format for direct logical ASCII addressing 4
logical addressing for I/O image elements 5
logical addressing for the status elements 7
logical addressing for integer elements 9
logical addressing for binary elements 11
logical addressing for floating-point elements 13
logical addressing for timer structures 14
logical addressing for counter structures 16
logical addressing for control block structures 18
Introduction
