Chapter 3
Force steps
84 Rockwell Automation Publication 1756-PM006I-EN-P - February 2018
For example, to exit this branch, the SFC
must be able to complete these actions.
• Execute Step_011 at least once
• Get past Tran_011 and execute
Step_012 at least once
• Determine that Tran_012 is TRUE
