Alliance Laundry Systems 75 - Page 70

M411433 73
Section 6 Adjustments
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Figure 45
WARNING! DO NOT
OPERATE WITHOUT
GUARDS IN PLACE.
T229IE3C
NOTE: Tumbler is shown with guards removed for ilustration purposes only.
Never operate the tumbler with the guards removed.
CYLINDER
DRIVE CHAIN
CYLINDER
SPROCKET
SHEAVE
IDLER
SPROCKET
JAM NUT
DRIVE
SPROCKET
IDLER
SHAFT
IDLER
HOUSING
GUIDE
RAIL
GUIDE RAIL
WASHER
GROUND WIRE
(Green)
MOTOR
PULLEY
BELT
1/2" (12.7 mm)
DEFLECTION
BELT ADJUSTING
BOLT AND NUT
1/2" (12.7 mm)
DEFLECTION
BELT/CHAIN
NONREVERSING
MODELS
