Section 6 Adjustments
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Figure 46
T324PE3B
LOCKNUT
ADJUSTING
BOLT
MOTOR
PULLEY
CYLINDER
MOTOR
IDLER HOUSING
ATTACHING
BOLT AND NUT
SHEAVE
GUIDE
RAILS
CYLINDER
SPROCKET
CYLINDER
DRIVE CHAIN
1/2" (13 mm)
DEFLECTION
1/2" (13 mm)
DEFLECTION
POLY
V-BELT
BELT/CHAIN
REVERSING
MODELS
