Alliance Laundry Systems STB75CE - Installation Instructions; Receiving Inspection

M413620
21
170 Pound Gas Tumbler
170 Pound Steam Tumbler
(Not Agency Listed)
Cylinder: 50-3/4" diameter x 42-1/2" deep (128.9 cm x 108.9 cm)
Perforated galvanized steel with four baffles;
170# dry weight (cotton load).
Cylinder Motor: 3/4 H.P. lifetime lubricated
Fan Motor: 3 H.P. lifetime lubricated
Gas Consumption: 395,000 BTU/hr (401 MJ/hr)
Air Flow: 2300 CFM at .3" W.C. (1083.3 liters/sec at .76 cm W.C.)
Net Weight (approx.): 1575 pounds (716 kg)
Cylinder: 50-3/4" diameter x 42-1/2" deep (128.9 cm x 108.9 cm)
Perforated galvanized steel with four baffles;
170# dry weight (cotton load).
Cylinder Motor: 3/4 H.P. lifetime lubricated
Fan Motor: 3 H.P. lifetime lubricated
Steam Consumption (maximum): 15 B.H.P (235.2 kg/hr)
502,500 BTU/hr (126,630 kcal/hr)
Operating Steam Pressure
(maximum):
125 psi (8.79 kg/sq cm)
Air Flow: 2300 CFM at .3" W.C. (1083.3 liters/sec at .76 cm W.C.)
Net Weight (approx.): 1675 pounds (761 kg)
