Allied Telesis x530 Series Quick Installation Guide

2 x530 Series Quick Installation Guide
Introduction
This Quick Installation Guide contains a short version of the
installation instructions for the x530 Series of Multi-Gigabit Layer 3
Ethernet Switches. For more instructions, refer to the x530
Series
Installation Guide for Standalone Switches and
x530 Series
Installation Guide for Virtual Chassis Stacking on the Allied Telesis
web site at www.alliedtelesis.com/us/en/services-support. This
guide contains the following sections:
 “Front Panels” next
 “PoE+ Power Budgets” on page 5
 “VCStack™ Feature” on page 5
 “Beginning the Installation” on page 6
 “Installing the Switch” on page 9
 “Ports” on page 14
 “Powering On the Switch” on page 16
 “LEDs” on page 18
 “Starting a Local Management Session” on page 21
 “Disabling the VCStack Feature” on page 22
 “Troubleshooting” on page 23
Front Panels
Here are the front panels of the switches in the x530 Series.
x530-28GTXm
x530-28GPXm
1 2
3
4
5 6
5
6
