4 x530 Series Quick Installation Guide
Here are the 100M/1/2.5/5Gbps Ethernet copper ports.
Here are the 1/10Gbps SFP+ ports.
The management panel is shown here.
Switch
100M/
1/2.5/5Gbps Ports
100M/
1/2.5/5Gbps Ports
with PoE+
x530-28GTXm 21 to 24
x530-28GPXm - 21 to 24
x530-52GTXm 41 to 48 -
x530-52GPXm - 41 to 48
Switch
Number of
1/10Gbps SFP+ Ports
x530-28GTXm 25 to 28
x530-28GPXm 25 to 28
x530-52GTXm 49 to 52
x530-52GPXm 49 to 52
USB Port
eco-friendly
Button
Console
Management
Port
Switch ID LED
