SPARE PART LISTS

PumpcodeEEE–ETZ,materialhousingparts:Polyethylene(PE)



Size   E15E.. E25E.. E40E..  E50E..

Item Pc. Description Material Part‐No. Part‐No. Part‐No. Part‐No.

1 2 Sidehousing PE 71501051 72501051 74001051 75001051

2 2 Tensiondisc 1.4301 71500822 72500822 74000822 75000822

3 2 Cover PE 71500951 72500951 74000951 75000951

4 1 Centerhousing PE 71501151 72501151 74001151 75001151

5 4 Sleeve PE 21501251 22501251 24001251 25001251

O‐ring,sleeve,codeEE. EPDM 92063172 93363272 95063372 96263472

6 8 O‐ring,sleeve,codeEN. NBR 92063171 93363271 95063371‐

  O‐ring.sleeve,codeET. FEP/FKM 92063159 93363259 95063359 96263459

7 2 Lockbolt PE 71501352 72501352 74001352 75001352

8 4 Threadbolt PE 20801452 21001452 21501452 21501452

9 2 Valvestop,dischargevalve PE 71501551 72501551 74001551 75001551

O‐ring,valvestopdischargevalve,codeEE. EPDM 92462572 93862672 95762772 97662872

10 2 O‐ring,valvestopdischargevalve,codeEN. NBR 92462571 93862671 95762771‐

  O‐ring,valvestopdischargevalve,codeET. FEP/FKM 92462559 93862659 95762759 97662859

11 2 Plug,sidehousing PE 71501751 72501751 74001751 75001751

O‐ring,plugsidehousing,codeEE. EPDM 92561072 94061372 96263472 97935372

12 2 O‐ring,plugsidehousing,codeEN. NBR 92561071 94061371 96263471‐

  O‐ring,plugsidehousing,codeET. FEP/FKM 92561059 94061359 96263459 97935359

13 1 Plug,centerhousing PE 71501951 72501951 74001951 75001951

O‐ring,plugcenterhousing,codeEE. EPDM 93363272 95063372 96263472 97363572

14 1 O‐ring,plugcenterhousing,codeEN. NBR 93363271 95063371 96263471‐

  O‐ring,plugcenterhousing,codeET. FEP/FKM 93363259 95063359 96263459 97363559

Cylindervalve,codeE.Z PTFE 71501660 72501660 74001660 75001660

  Ballvalve,codeE.E EPDM 11503272 12503272 14003272 15003272

15 4 Ballvalve,codeE.N NBR 11503271 12503271 14003271‐

  Ballvalve,codeE.S SS  11503222 12503222‐ ‐

  Ballvalve,codeE.T PTFE 11503260 12503260 14003260 15003260

16 4 Valveseat,ballvalves PE 21501852 22501852 24001852 25001852

Valveseat,cylindervalves PE 71501852 72501852 74001852 75001852

17 4 Shockabsorbers NR 11532285 11532285 14032285 14032285

18 2 Diaphragm,codeEE. EPDM 11503172 12503172 14003172 15003172

18 2 Diaphragm,codeEN. NBR 11503170 12503170 14003170‐

  Diaphragm,codeET. PTFE 11503167 12503167 14003167 15003167

19 * Housingbolt,cpl. 1.4305 71502022 72502022 74002022 75002022

20 1 Shaft 1.4301 21503022 22503022 24003022 25003022

21 2 Setscrew,shaft 1.4305 91022022 91222122 91622222 92022322

22 2 Shaftpistonring,cpl. PTFE 11504164 12504164 14004164 15004164

23 1 Airinlet PETP 11504784 11504784 14004784 14004784

24 1 Airfilter PE 11504351 11504351 14004351 14004351

25 1 Muffler,cpl. PE 11524451 11524451 14024451 15024451

26 1 PERSWINGP®aircontrolsystem,cpl. PETP 21500184 21500184 24000184 25020184

27** 6 O‐ring,airvalvehousing NBR 93550471 93550471 94651571 96653371

*E15andE25:6pieces;E40andE50:8pieces**includedinitem26



Allpartsinitalicsarenotproductwetted.

Pleaseseepage4forexplanationofthepumpcode.

Whenorderingpleasestatetheserialnumberofthepump.

Forsparepartlistsforspecialequipmentpleaseseepage24andthefollowingones.
