Almatec E 08 - ANSI Connections (W); Special Diaphragms (L+P)

26
cannotpreventthatliquidcanleavethepumpviathemuffler.ForhighersafetyrequirementstheALMATEC
barrierchambersystem(optionalequipmentcodeBS) isrecommended.Incaseofhumid surroundingaira
falsealertmayoccurdespiteoperatingthepumpwithdriedcompressedair.

Thediaphragmmonitoringsystemis
availableintwovariations:
 D1 Diaphragmsensor(Namur),alsoforexplosionproofarea
 D3 Diaphragmmonitoringsystemcompletewithsensorandcontroller

Thediap hragmsensorcaneitherbeconnectedtoanexistingco ntrollerwithNamurinlet(codeD1)ortothe
controller included(codeD3).
 Thewiring diagram andtechnical datacan be foundonthe controller itself.
For further details, please refer to the data delivered by the manufacturers of the components. The
controllershavetobeinstalledinasuitablecabinet.

Spare part list Diaphragm Monitoring
 E08 E10 E15 E25 E40 E50
Code Item Pc. Description Material Part‐No. Part‐No. Part‐No. Part‐No. Part‐No. Part‐No.
D1
51 1
Diaphragmsensor,
Namur
diverse 10077399 10077399 10077399 10077399 10077399 10077399
‐ 1 Adapter,muffler PE 61003352‐‐‐‐ ‐
D3
51 1
Diaphragmsensor,
Namur
diverse 10077399 10077399 10077399 10077399 10077399 10077399
‐ 1 Adapter,muffler PE 61003352‐‐‐‐ ‐
‐ 1 Trennschaltgerät diverse 10037099 10037099 10037099 10037099 10037099 10037099


Specialdiaphragms(optioncodeL+P)

CodeL:DiaphragmmadeofconductivePTFE/EPDM‐compound
FortheuseofthepumpsinthedevicegroupIICwithoutflankingmeasuresdiaphragmsmadeofconductive
PTFE/EPDMcompoundareavailable.

CodeP:DiaphragmmadeofmodifiedPTFE
Formedia withincreased diffusiontendency
(e.g.benzene,solvents)aswell asforapplicationwith priming
outofavacuumPTFE/EPDMcompounddiaphragmsmadeofmodifiedPTFEareavailable.

SparepartlistSpecialDiaphragms E15 E25 E40 E50
Code
Item Pc. Description Material Part‐No. Part‐No. Part‐No. Part‐No.
L 18 2 DiaphragmmadeofconductivePTFE
PTFEcond.
/EPDM
11503168 12503168 14003168 15003168
P 18 2 DiaphragmmadeofmodifiedPTFE
PTFEmodif.
/EPDM
11503198 12503198 14003198 15003198


CenterhousingwithANSIconnections(optioncodeW)

As standard the connections in the center housing [4] are prepared for a DIN flange connection, but it is
possibletoorderapreparationforANSIflangeconnectionalso.SotogetherwiththeappropiatecodeFANSI
flangeconnectionwiththreadbushingsand
flange‐O‐ringsisavailable.

SparepartlistANSICenterHousing  E15 E25 E40 E50
Code Item Pc. Description Material Part‐No. Part‐No. Part‐No. Part‐No.
W 4 1 CenterhousingANSI,codeE.. PE 71541151 72541151 74041151 75041151
 CenterhousingANSI,codeF.. PEconductive 71541155 72541155 74041155 75041155
 CenterhousingANSI,codeT.. PTFE 71541160 72541160 74041160 75041160
 CenterhousingANSI,codeU.. PTFEconductive 71541165 72541165 74041165 75041165



