Almatec E 08 - Code UEE - UTZ

21
PumpcodeUEE–UTZ,materialhousingparts:PTFEconductive

Size   E08U.. E10U.. E15U.. E25U.. E40U.. E50U..
Item Pc. Description Material Part‐No. Part‐No. Part‐No. Part‐No. Part‐No. Part‐No.
1 2 Sidehousing PTFEcond. 70801065 71001065 71501065 72501065 74001065 75001065
2 2 Tensiondisc 1.4301 70800822 71000822 71500822 72500822 74000822 75000822
3 2 Cover PEconductive 70800955 71000955 71500955 72500955 74000955 75000955
4 1 Centerhousing PTFEcond. 70801165 71001165 71501165 72501165 74001165 75001165
5 4 Sleeve PTFEcond. 20801268 21001268 21501268 22501268 24001268 25001268
O‐ring,sleeve,codeUE. EPDM‐91563072 92063172 93363272 95063372 96263472
6 8 O‐ring,sleeve,codeUN. NBR‐‐92063171 93363271 95063371 ‐
  O‐ring.sleeve,codeUT. FEP/FKM 91262959 91563059 92063159 93363259 95063359 96263459
7 2 Lockbolt PTFEcond. 70801365 71001365 71501365 72501365 74001365 75001365
8 4 Threadbolt PTFEcond. 70801465 70801465 20801465 21001465 21501465 21501465
9 2 Valvestop,dischargevalve PTFEcond. 70801565 71001565 71501565 72501565 74001565 75001565
10 2
O‐ring,valvestopdischarge
valve:
‐codeUE.
‐codeUN.
‐codeUT.


EPDM
NBR
FEP/FKM


‐
‐
91662359


91962472
‐
91962459


92462572
92462571
92462559


93862672
938
62671
93862659


95762772
95762771
95762759


97662872
‐
97662859
11 2 Plug,sidehousing PTFEcond. 70801765 71001765 71501765 72501765 74001765 75001765
12 2
O‐ring,plugsidehousing:
‐codeUE.
‐codeUN.
‐codeUT.

EPDM
NBR
FEP/FKM

‐
‐
91417859

92060272
‐
92060259

92561072
92561071
92561059

94061372
94061371
94061359

96263472
96263471
96263459

97935372
‐
97935359
13 1 Plug,centerhousing PTFEcond. 70801965 71001965 71501965 72501965 74001965 75001965
14 1
O‐ring,plugcenterhousing:
‐codeUE.
‐codeUN.
‐codeUT.

EPDM
NBR
FEP/FKM

‐
‐
92063159

92063172
‐
92063159

93363272
93363271
93363259

95063372
95063371
9
5063359

96263472
96263471
96263459

97363572
‐
97363559
Cylindervalve,codeU.Z PTFE 70801660 71001660 71501660 72501660 74001660 75001660
  Ballvalve,codeU.E EPDM 11003272 41503272 11503272 12503272 14003272 15003272
15 4 Ballvalve,codeU.N NBR‐‐11503271 12503271 14003271 ‐
  Ballvalve,codeU.S SS 11003222 41503222 11503222 ‐ ‐ ‐
  Ballvalve,codeU.T PTFE 11003260 41503260 11503260 12503260 14003260 15003260
16 4 Valveseat,ballvalves PTFEcond. 20801865 21001865 21501865 22501865 24001865 25001865
Valveseat,cylindervalves PTFEcond. 70801865 71001865 71501865 72501865 74001865 75001865
17 4 Shockabsorbers NR 10832285 10832285 11532285 11532285 14032285 14032285
Diaphragm,codeUE. EPDM‐11003172 11503172 12503172 14003172 15003172
18 2 Diaphragm,codeUN. NBR‐‐11503170 12503170 14003170 ‐
  Diaphragm,codeUT. PTFE 10803167 11003167 11503167 12503167 14003167 15003167
19 * Housingbolt,cpl. 1.4305 70802022 71002022 71502022 72502022 74002022 75002022
20 1 Shaft 1.4301
208030
22**
208030
22**
21503022 22503022 24003022 25003022
21 2 Setscrew,shaft 1.4305‐‐91022022 91222122 91622222 92022322
22 2 Shaftpistonring,cpl. PTFE‐‐11504164 12504164 14004164 15004164
23 1 Airinlet PETP 10804784 10804784 11504784 11504784 14004784 14004784
24 1 Airfilter PE‐‐11504351 11504351 14004351 14004351
25 1 Muffler,cpl. PE/Bz 10824451 10824451 11524434 11524434 14024434 14024434
26 1
PERSWINGP®aircontrol
system,cpl.
PETP 20800184 20800184 21500184 21500184 24000184 25020184
27** 6 O‐ring,airvalvehousing NBR 92651971 92651971 93550471 93550471 94651571 96653371
*E08andE10:4pieces;E15andE25:6pieces;E40andE50:8pieces**includedinitem26

Allpartsinitalicsarenotproductwetted.
Pleaseseepage4forexplanationofthepumpcode.
Whenorderingpleasestatetheserialnumberofthepump.
Forsparepartlistsforspecialequipmentpleaseseepage24andthefollowingones.
