T4PGF1 INSTRUCTION MANUAL Page 3
SHAW-ALMEX INDUSTRIES LIMITED June 14 2017
2. RECORD OF PURCHASE
Job Number
Date of Purchase
Model Number T4PGF1
Serial Number
Weight 45 lb. [21 kg}
Voltage 415 volt
Phase 3 phase
Cycle/Hertz 50/60
Amperage Maximum Per Platen 15 Amp
Total 30 Amp
Circuit Overcurrent Protection Required 30 Amp- 15 per platen, 10 amp pump
Temperature Sensor 100 Ω platinum RTD
Index of Protection – with case closed IP 67
Design of Protection – with case open IP 66
Ancillary Items platen cables, power supply cable
Spare Parts Fuses: 3 x 10 Amp, 3 x 1 1/4 Amp
Operating Instructions June, 2014
Supplements Omron E5CN-H manual
Service Bulletins none
Warranty Card yes
Drawings Model T4PGF1 drawing W1158-02
Parts Diagrams T4PGF1 Main Assembly, T4PGF1 Internal Assembly
