27
We reserve the right to modify technical specifications without prior notice.
UK830300/170717 © Alpha-InnoTec GmbH
Gerätebezeichnung
Heat pump type Brine/water ı Air/water ı Water/water applicable ı not applicable
Installation location Indoors ı Outdoors applicable ı not applicable
Conformity CE
Performance data Heating capacity/COP at
B0/W35 Standard point acc. to EN14511
2 condensers
1 condensers
kW ı
kW ı
B0/W45 Standard point acc. to EN14511 kW ı
B0/W35 Standard point acc. to EN255
2 condensers
1 condensers
kW ı
kW ı
Limits of application Heating circuit °C
Heat source °C
Additional operating points
Sound Sound level measured at distance of 1m around the device (in reverberating room) dB(A)
Sound power level according to EN12102 dB
Heat source Volume ow: minimum ow rate ı nominal ow rate ı maximum ow rate l/h
Pressure loss heat pump p (with cooling pK) ı volume ow bar (bar) ı l/h
Free compression heat pump p (with cooling pK) ı volume ow bar (bar) ı l/h
Anti-freeze agent monoethylene glycol
minimum concentration ı frost proof down to % ı °C
Heating circuit Volume ow: minimum ow rate ı nominal ow rate ı maximum ow rate l/h
Pressure loss heat pump p (with cooling pK) ı volume ow bar (bar) ı l/h
Free compression heat pump p (with cooling pK) ı volume ow bar (bar) ı l/h
General unit data Dimensions (see dimensional drawing for the specied unit size) unit size
Total weight (including cooling) kg (kg)
Additional weight module 1 kg
Additional weight module 2 kg
Connections Heating circuit
Heat source
Refrigerant Refrigerant type ı Quantity ı kg
Electric Voltage code ı all-pole circuit breaker heat pump *) ı A
Voltage code ı circuit breaker control voltage *) ı A
Voltage code ı circuit breaker electric heating element *) ı A
Heat Pump Effective power consumption in standard point B0/W35 according to EN14511: Power consumption ı current consumption ı cosφ kW ı A ı
Maximum device current within the limits of application A
Starting current: direct ı with soft starter A ı A
Protection type IP
Output electric heating element 3 ı 2 ı 1 phase kW ı kW ı kW
Components Circulating pump heating circuit at nominal ow rate: Power consumption ı current consumption kW ı A
Circulating pump heat source at nominal ow rate: Power consumption ı current consumption kW ı A
Passive cooling function only for units with designator K: Cooling output at nominal volume ow (15 °C heat source, 25 °C heating water) kW
Safety equipment Safety component heating circuit ı Safety component heat source scope of delivery: yes no
Heating and heat pump regulator scope of delivery: yes no
Electronic soft starter integrated: yes no
Expansion vessels Heat source: Scope of delivery ı Volume ı Initial pressure yes no ı l ı bar
Heating circuit: Scope of delivery ı Volume ı Initial pressure yes no ı l ı bar
Overow valve integrated: yes no
Vibration decouplers Heating circuit ı heat source scope of delivery: yes no
UK813196
*) comply with local regulations n.n. = not detectable
SWC 140H(/K)
• ı — ı
• ı
13,7 ı 4,5
13,9 ı 4,7
20 – 65
-5 – 25
42
55
2350 ı 3100 ı 4700
— ı
0,43 (0,41) ı 2350
25 ı -13
1200 ı 2400 ı 2900
— ı
0,59 (0,57) ı 1700
1
212 (227)
G1¼"AG
G1¼"AG
R407c ı 2,7
3~/PE/400V/50Hz ı C13
1~/N/PE/230V/50Hz ı B10
3~/N/PE/400V/50Hz ı C16
3,0 ı 5,8 ı 0,75
9,4
— ı 28
20
9 ı 6 ı 3
0,2 ı n.n.
0,25 ı n.n.
9,8
• ı
• ı 18 ı 0,5
• ı 35 ı 1,5
• ı
813173-a
SWC 170H(/K)
• ı — ı
• ı
16,7 ı 4,6
16,9 ı 4,7
20 – 65
-5 – 25
43
56
2700 ı 3600 ı 5000
— ı
0,36 (0,33) ı 2700
25 ı -13
1400 ı 2900 ı 3500
— ı
0,58 (0,55) ı 2050
1
220 (235)
G1¼"AG
G1¼"AG
R407c ı 3,6
3~/PE/400V/50Hz ı C13
1~/N/PE/230V/50Hz ı B10
3~/N/PE/400V/50Hz ı C16
3,63 ı 6,7 ı 0,78
11,0
— ı 30
20
9 ı 6 ı 3
0,2 ı n.n.
0,25 ı n.n.
9,0
• ı
• ı 18 ı 0,5
• ı 35 ı 1,5
• ı
813174-a
SWC 230(/K)
• ı — ı
• ı
22,1 ı 4,3
22,5 ı 4,5
20 – 55
-5 – 25
47
60
3700 ı 4900 ı 5900
— ı
0,74 (0,68) ı 3700
25 ı -13
1900 ı 3900 ı 4500
— ı
0,41 (0,38) ı 2700
2
345 (360)
R1½"IG
R1½"IG
R407c ı 4,45
3~/PE/400V/50Hz ı C16
1~/N/PE/230V/50Hz ı B10
5,14 ı 9,5 ı 0,78
12,5
— ı 29,5
20
— ı — ı
0,2 ı n.n.
0,35 ı n.n.
16,2
• ı
• ı 24 ı 0,5
• ı 50 ı 1,5
• ı
813175-a
SWC 330(/K)
• ı — ı
• ı
31,8 ı 4,1
17,6 ı 4,5
32,0 ı 4,3
17,9 ı 4,6
20 – 55
-5 – 25
47
60
5900 ı 7900 ı 10000
— ı
0,42 (0,35) ı 5950
25 ı -13
2700 ı 5200 ı 6900
— ı
0,70 (0,67) ı 3900
2
372 (390)
R1½"IG
R1½"IG
R407c ı 6,85
3~/PE/400V/50Hz ı C25
1~/N/PE/230V/50Hz ı B10
7,76 ı 14,4 ı 0,78
23,6
— ı 22
20
— ı — ı
0,36 ı n.n.
0,35 ı n.n.
26,5
• ı
• ı 24 ı 0,5
• ı 50 ı 1,5
• ı
813176-a
