Modbus Integrator's Guide for the CXC HP | 2 - Using Modbus
Table 26. AMPS HP System Data Points (continued)
Name Register Format
Inverter Imminent Shutdown 02:Input Status Boolean
TUS Synchronization Error 02:Input Status Boolean
TUS Internal Error 02:Input Status Boolean
TUS Configuration Error 02:Input Status Boolean
T2S Refusing Commands 02:Input Status Boolean
Missing T2S 02:Input Status Boolean
AC Output Power (VA) 04:Input Register 32-bit Floating Point
Average Output Loading 04:Input Register 32-bit Floating Point
DC Input 04:Input Register 32-bit Floating Point
System Mode 04:Input Register 32-bit Floating Point
• Line = 1
• Inverter = 2
• AC Input Power Limit = 3
• Bypass = 4
• Manual = 5
• Unlicensed = 6
Phase 1 Output Power (VA) 04:Input Register 32-bit Floating Point
Phase 2 Output Power (VA) 04:Input Register 32-bit Floating Point
Phase 3 Output Power (VA) 04:Input Register 32-bit Floating Point
Phase 1 Output Power (W) 04:Input Register 32-bit Floating Point
Phase 2 Output Power (W) 04:Input Register 32-bit Floating Point
Phase 3 Output Power (W) 04:Input Register 32-bit Floating Point
AC Output Voltage 04:Input Register 32-bit Floating Point
DC Input Current 04:Input Register 32-bit Floating Point
DC Input Voltage 04:Input Register 32-bit Floating Point
DC Input Power 04:Input Register 32-bit Floating Point
System On Bypass 04:Input Register 32-bit Floating Point
AC Input Power (VA) 04:Input Register 32-bit Floating Point
# Communicating Inverters 04:Input Register 32-bit Floating Point
Page 30 0350114-J0 Rev G
