Modbus Integrator's Guide for the CXC HP | 2 - Using Modbus
Table 26. AMPS HP System Data Points (continued)
Name Register Format
# Failed Inverters 04:Input Register 32-bit Floating Point
# Replace Fan Inverters 04:Input Register 32-bit Floating Point
# Comms Lost Inverters 04:Input Register 32-bit Floating Point
# Comms Lost T2S 04:Input Register 32-bit Floating Point
# T2S Not Accepting Commands 04:Input Register 32-bit Floating Point
# T2S 04:Input Register 32-bit Floating Point
Number Of Phases 04:Input Register 32-bit Floating Point
Number Of DC Input Groups
(Feeds)
04:Input Register 32-bit Floating Point
Supported by All T2S 04:Input Register 32-bit Floating Point
Supported by All Inverters 04:Input Register 32-bit Floating Point
Expected DC Input Current in AC
Failure
04:Input Register 32-bit Floating Point
Highest Phase Power % of Use 04:Input Register 32-bit Floating Point
Phase 1 AC Output Power (VA) 04:Input Register 32-bit Floating Point
Phase 1 Output Voltage 04:Input Register 32-bit Floating Point
Phase 1 Output Current 04:Input Register 32-bit Floating Point
Phase 1 Output Frequency 04:Input Register 32-bit Floating Point
Phase 1 Phase Power (VA) % of
Use
04:Input Register 32-bit Floating Point
Phase 1 Number Of Inverters On 04:Input Register 32-bit Floating Point
Phase 1 Phase Power (W) % of
Use
04:Input Register 32-bit Floating Point
Phase 1 Measured DC Input To
Output Power Ratio
04:Input Register 32-bit Floating Point
Phase 1 AC Input Power (W) 04:Input Register 32-bit Floating Point
Phase 1 AC Input Power (VA) 04:Input Register 32-bit Floating Point
Phase 1 AC Output Power (W) 04:Input Register 32-bit Floating Point
Phase 1 DC Input Power 04:Input Register 32-bit Floating Point
Phase 1 Current Number Of Re-
dundant Inverters
04:Input Register 32-bit Floating Point
0350114-J0 Rev G Page 31
