Alpine CDA-7998R User Manual

8-EN
Recalling the Stored Equalizer Curve
1 Press the EQ button and select the EQ mode.
2 Press and hold the EQ button for at least 3 seconds.
3 Press any one of the Preset buttons (1 through 6) to
activate your desired curve.
4 Press the EQ button to return to the normal mode.
NOTES
• EQ mode is automatically cancelled if no buttons
are pressed within 15 seconds.
• This function is inoperable when DEFEAT is ON(refer to
page 7).
• When the ALPINE Digital Audio Processor is connected to
the Digital Output Connector, the Equalizer, Crossover, Bass
Focus, Time Correction and MX (Media Xpander) functions
cannot be used in the built-in CD mode.
The functions on the connected Digital Audio Processor side
take preference.
• If you do not adjust the factory settings of (FLAT/POPS/
ROCK/NEWS), the factory set display (FLAT/POPS/ROCK/
NEWS) is shown preferentially.
→ BAND1 → BAND2 → BAND3 → BAND4 → BAND5
Adjusting and Storing the Equalizer
Curve
You can modify the Equalizer settings to create a
response curve more appealing to your personal taste.
1 Press the EQ button and select the EQ mode.
2 Press and hold the EQ button for at least 3 seconds.
3 Press the BAND button to select your desired
frequency band.
4 Press the g DN button or the f UP button to
select your desired frequency.
Adjustable frequency bands: 20Hz to 20KHz(in 1/3
octave steps)
5 Turn the Rotary encoder to adjust the level.
6 Press the SOURCE button to select your desired band
width (Q).
Adjustable band width: 1, 2, 3.
To store the adjusted contents
1) Press and hold any one of the Preset buttons (1
through 6) for at least 2 seconds into which you
wish to store the adjusted curve.
7 For setting another channel, repeat the steps 3 to 6.
8 After setting, press the EQ button to return to the
normal mode.
NOTES
• The frequencies of adjacent bands cannot be adjusted within
4 steps.
• EQ mode is automatically cancelled if no buttons are
pressed within 15 seconds.
• This function is inoperable when DEFEAT is ON (refer to
page 7).
• When the ALPINE Digital Audio Processor is connected to
the Digital Output Connector, the Equalizer, Crossover, Bass
Focus, Time Correction and MX (Media Xpander) functions
cannot be used in the built-in CD mode.
The functions on the connected Digital Audio Processor side
take preference.
Basic Operation
BAND
SOURCE
Rotary encoder
Preset buttons
(1 through 6)
g DN
f UP
EQ
