Alpine CDE-135EBT User Manual

12-EN
* The illustration is for CDE-135EBT.
Adjusting Subwoofer Level/Bass Level/Mid
Level/Treble Level/Balance (Between Left
and Right)/Fader (Between Front and Rear)/
Loudness/Defeat
1 Press AUDIO repeatedly to choose the desired mode.
Each press changes the mode as follows:
SUBW
*1
 BASS
*2
 MID
*2
 TREBLE
*2
 BAL  FAD  LOUD
*2
 DEFEAT  VOLUME  SUBW
*1 When the subwoofer mode is set to OFF, its level cannot be
adjusted, refer to “Turning Subwoofer ON/OFF” on page 13.
*2 Adjustable only when DEFEAT is OFF.
Notes
• If no operation is performed for 5 seconds, the unit automatically
returns to normal mode.
• Loudness introduces a special low- and high-frequency emphasis at low
listening levels. This compensates for the ear’s decreased sensitivity to
bass and treble sound.
2 Turn the Rotary encoder until the desired sound is
obtained in each mode.
By setting DEFEAT ON, previously adjusted level settings of
BASS, MID, and TREBLE will return to the factory defaults.
Sound Setting
You can flexibly customize the unit to suit your own preference and
usage. From the AUDIO SETUP menu, Audio Setting can be modified.
1 Press and hold AUDIOSETUP for at least 2 seconds to
activate the SETUP mode.
2 Turn the Rotary encoder to select AUDIO, and then press
ENTER.
BLUETOOTH  GENERAL  AUDIO  DISPLAY  iPod & USB
3 Turn the Rotary encoder to select the desired sound
setting menu, and then press ENTER.
FAC TORY EQ
*1/*2
 3BAND EQ
*1/*3
 HPF
*1
 SUBWOOFER 
SUBW LPF
*4
 SUBW PHASE
*4
 SUBW SYS
*4
*1 Adjustment cannot be performed when DEFEAT is set to ON.
*2 Any changes made to either FACTORY EQ or 3BAND EQ are
reflected in the others’ settings.
*3 In step 3, three sound adjustment items (Bass, Mid and Treble)
can be selected in 3BAND EQ mode, turn the Rotary encoder
to select the desired item, and then press ENTER to continue
to step 4.
*4 These functions are inoperable when Subwoofer is set to OFF.
4 Turn the Rotary encoder to change the setting, and then
press ENTER.
(e.g. Select SUBWOOFER ON or SUBWOOFER OFF)
5 Press and hold AUDIOSETUP for at least 2 seconds to
return to normal mode.
Notes
•Pressing  returns to the previous Sound menu mode.
• If no operation is performed for 60 seconds, Sound menu mode is
cancelled.
10 typical equalizer settings are preset at the factory for a variety of
musical source material. USER settings are created in the 3BAND EQ
mode.
USER  FLAT (Initial setting)  POPS  ROCK  NEWS 
JAZZ  ELEC DANCE  HIP HOP  EASY LIS  COUNTRY 
CLASSICAL
You can modify the Equalizer settings to create a response curve more
appealing to your personal taste. The setting of Bass, Mid and Treble can
be adjusted in this mode.
Setting the Bass Control
1 After selecting BASS from the 3BAND EQ adjustment
mode, turn the Rotary encoder to select the desired Bass
setting item, and then press ENTER.
WIDTH (Q)  CENTER FRQ  LEVEL
2 Turn the Rotary encoder to select the desired setting
value, and then press ENTER.
Sound Setting
Subwoofer 0 ~ +15
Bass level -7 ~ +7
Mid level -7 ~ +7
Treble level -7 ~ +7
Balance L15 ~ R15
Fader R15 ~ F15
Loudness ON/OFF
Defeat ON/OFF
Volume 0 ~ 35
AUDIO/SETUP
Rotary encoder//ENTER
Use steps 1 to 5 to select the category you wish to modify. For
details on how to change each setting, see the following sec-
tions below.
Equalizer Presets (FACTORY EQ)
Adjusting the Parametric Equalizer Curve
(3BAND EQ)
00ALPINE.book Page 12 Sunday, November 20, 2011 6:35 PM
