36-EN
Connect USB Memory
Connect the USB cable to the Rear USB connector of the unit, and then
secure the connection using the lock case supplied with USB cable as
shown below.
Remove USB Memory
Pull out USB Memory squarely from the USB cable.
Notes
• When removing USB Memory, pull it out straight.
• If sound is not output or USB Memory is not recognised even when USB
Memory is connected, remove USB Memory once, then connect it again.
• Change to a source other than the USB Memory mode, then remove the
USB Memory. If the USB Memory is removed in the USB Memory
mode, data may be damaged.
• Route the USB cable away from another cables.
Mounting the Microphone
For the sake of safety, mount the microphone in the following location.
• In a stable and secure location.
• In a location that does not inhibit safely driving the vehicle.
• Mount the microphone in a location where the driver’s voice can
easily be picked up.
Choose a location for the microphone that can easily pick up the driver’s
voice. Requiring the driver to move towards the microphone for
audibility causes a distraction that could be dangerous.
When Connect iPod/iPhone to Rear USB
Connector (CDE-135EBT only) (sold
separately)
Rear USB Memory Connection
(CDE-135EBT only) (sold separately)
Interface cable for iPod (Included with iPod/iPhone)
This unit
lock case
Cable (sold separately)
Rear USB Connector
This unit
USB Memory
(sold separately)
lock case
Cable (sold separately)
USB Connector
This unit
USB Memory
(sold separately)
USB Connector
Cable (sold separately)
00ALPINE.book Page 36 Sunday, November 20, 2011 6:35 PM
