Alpine TDA-7567R User Manual

14
EnglishEnglish
Detachable Front
Panel
Attaching the Front
Panel
1. First, insert the right side of the front panel
into the main unit. Align the groove on the
front panel with the projection on the main
unit.
2. Push the left side of the front panel until it
locks firmly into the main unit.
1
Note: Before attaching the front panel, make
sure that there is no dirt or dust on the
connector terminals and no foreign
object between the front panel and the
main unit.
1
2

Alpine TDA-7567R Specifications

General

Brand	Alpine
Model	TDA-7567R
Category	Car Receiver
Language	English
