H38x/EN GL/D11 Global Documentation
Page 28/53
DS Agile H38x
NA IRIG-B connector NA
4.6.2.7
Pulse magnetic field immunity
Standard: EN 61000-4-9
Application mode Group under test Test level
NA Housing Class 5 : 1000A/m
NA Power supply NA
NA Alarm contact NA
NA Earth connector NA
NA Copper Ethernet port NA
NA IRIG-B connector NA
4.6.2.8
Damped oscillatory magnetic field immunity
Standard: IEC 61850-3/ EN 61000-4-10
Application mode Group under test Test level
NA Housing Class 5 : 100A/m ; 100KHz & 100A/m ; 1MHz
NA Power supply NA
NA Alarm contact NA
NA Earth connector NA
NA Copper Ethernet port NA
NA IRIG-B connector NA
4.6.2.9
Conducted immunity, common mode disturbance
Standard: IEC 61850-3
/ EN 61000-4-16
Application mode Group under test Test level
CM Housing NA
CM Power supply Class 4 : 30V continuous disturbance &
300V short duration disturbance
CM Alarm contact Class 4 : 30V continuous disturbance &
300V short duration disturbance
CM Earth connector NA
CM Copper Ethernet port Class 4 : 30V continuous disturbance &
300V short duration disturbance
CM IRIG-B connector Class 4 : 30V continuous disturbance &
300V short duration disturbance
4.6.2.10
Damped oscillatory wave immunity
Standard: IEC 61850-3
/ IEEE 1613 / ANSI/IEEE C37.90.1 / EN 61000-4-18
Application
mode
Group under test Test level
CM Housing NA
CM Power supply Slow damped oscillatory wave, Class 3 : ± 2,5kV ;
