Global Documentation H38x/EN GL/D11
DS Agile H38x
Page 29/53
100kHz & ±2,5kV ; 1MHz
Fast damped oscillatory wave, Class 4 : ± 4kV ;
3MHz & ± 4kV ; 10MHz & ± 4kV ; 30MHz
CM Alarm contact Slow damped oscillatory wave, Class 3 : ± 2,5kV ;
100kHz & ±2,5kV ; 1MHz
Fast damped oscillatory wave, Class 4 : ± 4kV ;
3MHz & ± 4kV ; 10MHz & ± 4kV ; 30MHz
CM Earth connector NA
CM Copper Ethernet port Slow damped oscillatory wave, Class 3 : ± 2,5kV ;
100kHz & ±2,5kV ; 1MHz
Fast damped oscillatory wave, Class 4 : ± 4kV ;
3MHz & ± 4kV ; 10MHz & ± 4kV ; 30MHz
CM IRIG-B connector Slow damped oscillatory wave, Class 3 : ± 2,5kV ;
100kHz & ±2,5kV ; 1MHz
Fast damped oscillatory wave, Class 4 : ± 4kV ;
3MHz & ± 4kV ; 10MHz & ± 4kV ; 30MHz
DM Housing NA
DM Power supply Slow damped oscillatory wave, Class 3 : ± 1kV ;
100kHz & ±2,5kV ; 1MHz
Fast damped oscillatory wave, Class 4 : NA
DM Alarm contact Slow damped oscillatory wave, Class 3 : ± 1kV ;
100kHz & ±2,5kV ; 1MHz
Fast damped oscillatory wave, Class 4 : NA
DM Earth connector NA
DM Copper Ethernet port NA
4.6.2.11
Conducted emission limits
Standard: IEC 61850-3
/ EN 55022 / IEC 60255-25 / CISPR 22
Application mode Group under test Test level
NA Housing NA
NA Power supply Class A: 0,15 to 0,5MHz ; 79dBμV quasi-
peak ; 66dBμV average & 0,5 to 30MHz ;
73dBμV quasi-peak ; 60dBμV average
NA Alarm contact NA
NA Earth connector NA
NA Copper Ethernet port Class A : 0,15 to 0,5MHz ; 97dBμV quasi-
peak ; 84dBμV average & 0,5 to 30MHz ;
87dBμV quasi-peak ; 74dBμV average
NA IRIG-B connector Class A : 0,15 to 0,5MHz ; 97dBμV quasi-
peak ; 84dBμV average & 0,5 to 30MHz ;
87dBμV quasi-peak ; 74dBμV average
4.6.2.12
Radiated emission limits
Standard: IEC 61850-3/ EN 55022 / IEC 60255-25 / CISPR 22
Application mode Group under test Test level
NA Housing Class A : 30 to 230MHz ; 40dBμV/m
quasi-peak & 230 to 1GHz ; 47dBμV/
m quasi-peak
NA Power supply NA
