Altai C2s Dual-Band 2x2 802.11ac WiFi AP/Bridge
Installation Guide
Altai Technologies Ltd. All rights reserved
3. Electrical and Lightning Protection
3.1. Surge Protector
It is strongly advised the C2s unit be installed with surge protector
(ordered separately), especially for outdoor deployment, to protect it
against electrical surge. The surge protector should be grounded
properly and installed as close to the C2s unit as possible in order to
prevent the C2s from the electrical damage.
3.2. Lightning Protection System
The C2s unit should be installed with a lightning rod and protected by
relevant lightning protection system to avoid any potential electrical
damage caused by lightning.
3.3. LAN Cable for Outdoor Installation
STP cable with shielded connectors is required to protect the C2s
against ESD. Follow the instruction to crimp the cable:
1. Cut about 4cm of the wire coating.
2. Untwist eight wires with the order from left to right: Orange White,
Orange, White Green, Blue, White Blue, Green, White Brown,
Brown. The order will be the same on both sides.
3. Straighten eight wires and cut the wire with only 2cm extension
4. Insert the wires into an RJ45 modular jack. The hook should face
down. All eight wires should touch the top of the jack.
5. The foil and the shield of RJ45 connector should have direct
contact.
6. Insert the modular jack into the crimping tool. Press down on the
tool firmly.
