INSTALLATION
Converge® ▪ Operator’s Manual ▪ MN-47239 ▪ Rev 3 ▪ 5/23
21
INSTALLATION
Dimension Drawings
32-1/16"
815mm
6-5/16"
4-1/16"
160mm
103mm
ADJUSTABLE LEGS
11-1/2" 292mm
CAVITY HEIGHT
14 - 3/8" 366mm
CAVITY WIDTH
5-7/8" 150mm
MOBILE BASE
40-1/4" 1023mm
37-9/16" 955mm
7-3/4"
5-7/8"
197mm
149mm
SEISMIC LEGS
7 - 1/16" 180mm
BACK WALL
CLEARANCE
24 - 7/16" 621mm
4-7/16" 112mm
26-9/16"
674mm
A
ELECTRICAL
CONNECTION
60-1/8"
1527.23mm
2-11/16" 68mm
3-3/4" 95mm 2-9/16" 66mm
2-1/4" 57mm
11-1/2" 292mm
14-5/16" 364mm
7-15/16" 201mm
16-1/4" 412mm
DETAIL A
OVEN DRAIN
MANUAL DRAIN
Y1 STEAM INJECTION
34-11/16"
22" 559mm
18-3/8"
467mm
10-7/8"
882mm
277mm
a
b
c
d
a
c
d
b
Chamber width
Chamber depth
Chamber height
Chamber height with wire shelf
4-3/4 "
(121mm)
4-3/16
"
(106mm)
14-3/8
"
(366mm)
21-1/8
"
(537mm)
Y2 CONDENSATE/
RINSE/WASH WATER
Y5 HOSE REEL
