(6.1) Technical Specifications
Output Power Eco Mode: 50 W (peak)
Standard Mode: 200 W (peak)
Drivers Low-Frequency: 6.5” (165.1 mm) woofer
High-Frequency: 1.0” (25.4 mm) tweeter
Max SPL 106 dB
Frequency Response 60 Hz – 20 kHz
Connectors (2) Combo XLR-1/4” (6.35 mm) Inputs
(1) 1/8” (3.5 mm) AUX Input
(1) USB Charging Port
(1) XLR Line Out
(1) RCA Line Out
Charge Port 5V, 2.1 A
Speaker Pole Cup Size 35 mm
Bluetooth Specifications Profile: A2DP, AVRCP
Version: 5.0
Frequency: 2402 – 2480 MHz
Maximum Transmission Power: 10 dBm
Protocol: BLE
Codec: SBC
Range: 100 ft. (30.5 m)
Battery Type: 6.6 Ah, 12 V, Lithium Ion
Life: Eco Mode: up to 24 hours; Standard Mode: up to 20 hours
Charging Time: 12 hours
Power Connection: IEC
Voltage: 100–240 VAC, 50/60 Hz, 120 W; 220–240 VAC, 50/60
Hz; 120 W
Fuse: 100–120 V, T1.6AL AC250 V; 220–240 V, T0.8AL AC250 V
Dimensions
(height x width x depth)
11.8” x 8.6” x 10.0”
299 x 219 x 254 mm
Weight 11.9 lbs.
5.4 kg
Specifications are subject to change without notice.
Bluetooth and wireless reception and range are affected by walls, obstructions, and movement.
For optimal performance, place the product in the center of the room so it is unobstructed by
walls, furniture, etc. Battery life may vary based on temperature, age, and volume usage of
product.
