21
Then the test mode screen indicates that the ignition is firing and permits the
operator to select the output to be fired.
AT
PRESS TO PRESS TO PRESS TO
SELECT SELECT EXIT
PREVIOUS THE NEXT
OUTPUT
OUTPUT
ESC
Test-Mode selection rotates as described below.
MODEL # ROTATION SEQUENCE
791963-8X: ALL, A, B, C, D, E, F, K, L
791963-16X: ALL, A, B, C, D, E, F, K, L, M, N, P, R, S, T, U, V, ALL
