ADDITIONAL COMPONENTS REQUIRED
•
Electric Motor: 850 - 1000Kv:
Maximum diameter 41mm.
Maximum height 41mm.
Pinion shaft diameter 5 mm.
•
Speed controller: minimum 60A,
extreme 3D Flight 70-90A.
•
Batteries: 6S-1800 mAh ( 1500 - 2600 mAh ) .
•
1 flybarless 3 axis control unit.
•
Radio power system, if not integrated with the ESC.
•
3 micro cyclic servos.
•
1 mini (midi) tail rotor servo.
•
6 channel radio control system on 2.4 GHz.
TOOLS, LUBRICANTS, ADHESIVES
•
Generic pliers.
•
Hexagonal driver, size 1.5,2,2.5mm.
•
5.5mm Socket wrench (for M3 nuts).
•
7mm Hex fork wrench (for M4 nuts).
•
Medium threadlocker (eg. Loctite 243).
•
Strong retaining compound (eg. Loctite 648).
•
Spray lubricant (eg. Try-Flow Oil).
•
Grease ( eg. Microlube GL261 ).
•
Cyanoacrylate adhesive.
•
Pitch Gauge (for set-up).
•
Soldering equipment (for motor and ESC wiring).
INSIDE THE MAIN BOX THERE ARE:
MANUAL
BOX 2
BOX 1
BOX 4
BOX 3
MAIN BOX
INSIDE THE MAIN BOX
BOX 1
Canopy
Frames
Blade Holder
Landing Gear
Battery Support
Tail Fin Assembly
BOX 2
Combo Components (Optional)
BOX 3
Tail boom
Carbon Rod
Blades + Tail Blades
BOX 4
Mechanical parts & Bags
The assembly process is described in the following chapters. Each chapter
provides you with the box and bag you will need for that chapter.
The information is printed at the bottom of every page.
