CHAPTER 3: OPERATING INSTRUCTIONS
DUAL PULSE 125
STORED ENERGY RESISTANCE WELDING POWER SUPPLY
3-4 990-270
Section II: Operation
Programming Weld Schedules
Program State
Changes to Schedules 1 through 7 must be made in the PROGRAM State.
Press SCHEDULE to select the Schedule Number you wish to change.
Press either 1ST PULSE PROGRAM or [2ND PULSE PROGRAM] to enter the PROGRAM State. The
PROGRAM indicator will flash next the Program Key selected and the %ENERGY for the Pulse
Selected will be displayed and can be changed.
NOTE: A flashing display of [ ] after pressing either PROGRAM Key indicates that the
Schedule cannot be changed because the Schedule Protection Feature is ON. See Page 3-7. Press RUN
to clear the error code and return to the RUN State.
Change 1st Pulse
Press ENERGY to change the % Energy. When the key is released, the new %ENERGY for the
1ST Pulse will be displayed.
Change 2nd Pulse
If the 2ND PULSE INDICATOR is NOT flashing, press 2ND PULSE. When the 2ND Pulse is displayed
press ENERGY to change %ENERGY. If a 2ND Pulse is NOT desired, set its %ENERGY to
000%.
You may either SAVE these changes or transfer them to Schedule 0 in the RUN state.
Press
SAVE and hold down for 1 second. The ENERGY LEVEL DISPLAY will go blank to indicate
that the schedule is being saved (written) in the 125DP's permanent memory.
This "new" information will replace the "old" information previously saved for this Schedule.
Schedules which are saved are remembered even if the power is switched to OFF. Schedules 0 through
7 can be saved.
After the Schedule has been saved the 125DP will automatically re-enter the RUN State.
NOTE: After entering the RUN state the capacitors will begin to charge to the PROGRAMMED level.
