Ambit PIB v1.5 - Page 8

Section 1 • Introduction
4
Indicates which tubing connects to
the solution container
Indicates which tubing connects to
the patient
Bolus
Program lockout
Boluslockouttimeinhours:minutes
Bolus volume in milliliters
Volume in milliliters
Basal infusion rate in ml/hr
Number of boluses delivered
Number of bolus requests
Volume to be infused
RUN/PAUSE button
BOLUS button
To patient
To solution container
Cassette
shaft
(side view of cassette)
