• When the setup button is clicked, a live stream of the video is shown. The user can then set up to 4 regions, each
with their own region name, sensitivity (1-100), and threshold (1-100). Each region has a specific color, and the
region selector tool is displayed when the mouse is moved to the top of the screen.
Sensitivity is the amount of change required to increase the motion detected by a percentage. The lower the
sensitivity, the more movement is required to trigger an alarm.
Threshold is the level that the motion detection needs to reach to trigger an alarm. The lower the threshold, the
more likely that motion will trigger an alarm.
To designate a zone, click and drag the mouse over the area desired. When a colored box is displayed over the live
feed, that area is now enabled for motion detection.
After the motion detection zone is set, click the enter button to exit the motion detection screen.
Remember to click the save button on the motion detection settings screen, otherwise the motion detection zones
will not go into effect. Clicking the cancel button to leave the motion detection zone and will not save the zone
setup.
• Record: This checkbox allows the user to enable the camera to record video when a motion detection alarm is
triggered.
• Record Delay: This field specifies in seconds how long the delay between alarm activation and recording should be.
• Relay Out: This checkbox allows the user to enable the camera to trigger a connected alarm (connected to the
alarm port on the back of the camera) when a motion detection alarm is triggered.
• Alarm Delay: This field specifies in seconds how long the delay between alarm activation and Relay alarm
activation should be.
• Send Email: This checkbox allows the user to enable the camera to send an email when a motion detection alarm
is triggered.
• PTZ: This checkbox allows the user to enable the camera to send an alert based on PTZ (Pan/Til) functions of the
camera.
• Snapshot: This checkbox allows the user to enable the camera to take a snapshot when a motion detection alarm
is triggered.
To reset to default settings, click the Reset Defaults button. To refresh the page, click the Refresh button. To save
the settings, click the Save button.
Video Tamper
This tab allows the user to modify video tamper settings. Below is an explanation of the fields on the Video Tamper
tab:
• Enable: This checkbox enables a video tamper alarm for the camera.
• Schedule: Clicking this button opens a weekly schedule that can be used to set times.
o Click and drag to set video tampering for certain days of the week. Also, periods of video tampering can be set
for each day and enabled using the period settings on the bottom half of the screen. There are a total of 6 periods
that can be set.
• Record: This checkbox allows the user to enable the camera to record video when a video tampering alarm is
triggered.
• Record Delay: This field specifies in seconds how long the delay between alarm activation and recording should be.
• Relay Out: This checkbox allows the user to enable the camera to trigger a connected alarm (connected to the
alarm port on the back of the camera) when a video tamper alarm is triggered.
