Specification
Page 2-3
))
))
) Onboard connector and pin-header
One floppy drive connector
Two ATA-133 IDE connectors
Four extra USB2.0 ports
One CD-IN and One AUX-IN connectors
One S/PDIF in/out connector
One IR connector
One Game port connector
One Serial Port (COM2) connector
Two 1394 connectors (Optional)
Four S-ATA connectors (two Optional)
Three Fan connectors
Front Panel Controller
Supports Reset & Soft-Off switches
Supports HDD & Power LEDs
Supports PC speaker
One Front Panel Audio connector
Expansion Slots
One AGP slot supporting 1.5v 4X/8X AGP card
- AGP v3.0 compliant
Five PCI slots
with Bus Master support
- PCI v2.2 compliant
Other Features
Magic Health – A quick “dashboard” display at POST to show hardware
status. Helps to detect faults early.
EZ Boot – An easy way let end-user can choose to boot from hard drive,
CD-ROM, floppy, …
KBPO – Keyboard power on, turn on the computer from keyboard
Supports “Cool’n’ Quiet” power saving technology
