Installation
Page 3-6
3-4 Expansion Slots
AGP Slot
The mainboard is equipped with an AGP
slot. Make sure you install a card that
supports the 1.5V specification.
PCI Slots
The mainboard is equipped with 5 PCI
slots.
PCI Slots
AGP Slot
AGP Card Installation Caution
When installing the AGP card make sure the AGP card edge
connector is inserted fully into the slot and the slot clicker is locked.
To Next Page
