7 | P a g e
FIGURE 1.3 6U REAR PANEL DESCRIPTION
(5.) GPIB
(2.) Remote
Sense
(6.) RS-232
(7.) LAN
(1.) J1 Analog Programming
Port (25P D-SUB)
(3.) & (4.) Master/Slave Input &
Output Connector (9P D-SUB)
(8.) USB
(9.) AC Input
(10.) DC Output

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Ametek AMREL SPS Series and is the answer not in the manual?

Ametek AMREL SPS Series Specifications

General IconGeneral
TypeProgrammable DC Power Supply
Operating Temperature0°C to 50°C
Storage Temperature-20°C to 70°C
CoolingForced Air
Output VoltageUp to 600V (depending on model)
Control InterfaceRS232, USB, GPIB, Ethernet
Programming Accuracy±0.05%
Readback Accuracy±0.05%
Humidity5% to 95% non-condensing
DimensionsVaries by model
WeightVaries by model
