Modules  24
nVision Operation Manual

ABSOLUTE PRESSURE SPECIFICATIONS
psiA (Pressure with BARO module)
30 psi module
0.200 to 14.500 psiA: ± 0.011 psiA
14.500 to 44.500 psiA:
±(0.025% of Reading)
+ 0.003 psiA
100 psi module
0.200 to 14.500 psiA: ± 0.011 psiA
14.500 to 44.500 psiA: ± 0.011 psiA
44.500 to 114.500 psiA: ±(0.025% of Reading)
300 psi module
0.20 to 14.50 psiA: ±0.01 psiA
14.50 to 104.50 psiA: ± 0.03 psiA
104.50 to 314.50 psiA: ±(0.025% of Reading)
1000 psi module
14.5 to 314.5 psiA: ± 0.2 psiA
314.5 to 1014.5 psiA: ±(0.05% of Reading)
3000 psi module
14.5 to 914.5 psiA: ± 0.5 psiA
914.5 to 3014.5 psiA: ±(0.05% of Reading)
10 000 psi module
15 to 3015 psiA: ± 2 psiA
3015 to 10 015 psiA: ±(0.05% of Reading)
15 000 psi module
15 to 4515 psiA: ± 3 psiA
4515 to 15 015 psiA: ±(0.05% of Reading)
barA (Pressure with BARO module)
3 bar module
0.0138 to 1.0000 barA: ±0.0008 barA
1.0000 to 4.0000 barA:
±(0.025% of Reading)
+0.0003 barA
10 bar module
0.0138 to 1.0000 barA: ±0.0008 barA
1.0000 to 4.0000 barA: ± 0.0010 barA
4.0000 to 11.0000 barA: ±(0.025% of Reading)
30 bar module
0.014 to 1.000 barA: ±0.001 barA
1.000 to 10.000 barA: ± 0.003 barA
10.000 to 31.000 barA: ±(0.025% of Reading)
100 bar module
1.000 to 31.000 barA: ± 0.015 barA
31.000 to 101.000 barA: ±(0.05% of Reading)
300 bar module
1.00 to 91.00 barA: ± 0.05 barA
91.00 to 301.00 barA: ±(0.05% of Reading)
700 bar module
1.00 to 211.00 barA: ± 0.11 barA
211.00 to 701.00 barA: ±(0.05% of Reading)
1000 bar module
1.00 to 301.00 barA: ± 0.15 barA
301.00 to 1001.00 barA: ±(0.05% of Reading)
MPaA (Pressure with BARO module)
300 kPa module
1.38 to 100.00 kPaA:
±0.08 kPaA
100.00 to 400.00 kPaA: ±(0.025% of Reading)
+0.03 kPaA
1 MPa module
0.00138 to 0.10000 MPaA: ±0.00008 MPaA
0.10000 to 0.40000 MPaA: ± 0.00010 MPaA
0.40000 to 1.10000 MPaA: ±(0.025% of Reading)
3 MPa module
0.0014 to 0.1000 MPaA: ±0.0001 MPaA
0.1000 to 1.000 MPaA: ± 0.0003 MPaA
1.000 to 3.1000 MPaA: ±(0.025% of Reading)
10 MPa module
0.1000 to 3.1000 MPaA: ± 0.0015 MPaA
3.1000 to 10.1000 MPaA: ±(0.05% of Reading)
30 MPa module
0.100 to 9.100 MPaA: ± 0.005 MPaA
9.100 to 30.100 MPaA: ±(0.05% of Reading)
70 MPa module
0.100 to 21.100 MPaA: ± 0.011 MPaA
21.100 to 70.100 MPaA: ±(0.05% of Reading)
100 MPa module
0.100 to 30.100 MPaA: ± 0.015 MPaA
30.100 to 100.100 MPaA: ±(0.05% of Reading)
kg/cm2A (Pressure with BARO module)
3 kg/cm
2
module
0.0141 to 1.0000 kg/cm
2
A: ±0.0008 kg/cm
2
A
1.0000 to 4.0000 kg/cm
2
A: ±(0.025% of Reading)
+0.0003 kg/cm
2
A
10 kg/cm
2
module
0.0141 to 1.0000 kg/cm
2
A: ±0.0008 kg/cm
2
A
1.0000 to 4.0000 kg/cm
2
A: ± 0.0010 kg/cm
2
A
4.0000 to 1 1.0000 kg/cm
2
A: ±(0.025% of Reading)
30 kg/cm
2
module
0.014 to 1.000 kg/cm
2
A: ±0.001 kg/cm
2
A
1.000 to 10.000 kg/cm
2
A: ± 0.003 kg/cm
2
A
10.000 to 31.000 kg/cm
2
A: ±(0.025% of Reading)
100 kg/cm
2
module
1.000 to 31.000 kg/cm
2
A: ± 0.015 kg/cm
2
A
31.000 to 101.000 kg/cm
2
A: ±(0.05% of Reading)
300 kg/cm
2
module
1.00 to 91.00 kg/cm
2
A: ± 0.05 kg/cm
2
A
91.00 to 301.00 kg/cm
2
A: ±(0.05% of Reading)
700 kg/cm
2
module
1.00 to 211.00 kg/cm
2
A: ± 0.11 kg/cm
2
A
211.00 to 701.00 kg/cm
2
A: ±(0.05% of Reading)
1000 kg/cm
2
module
1.00 to 301.00 kg/cm
2
A: ± 0.15 kg/cm
2
A
301.00 to 1001.00 kg/cm
2
A: ±(0.05% of Reading)
