931003E / 0620 4. FIRMWARE COMMANDS AND RESPONSES
Example Responses:
$D0100000003077<CR> 1000 V, negative, not overloaded, disabled.
$D0100000002076<CR> 1000 V, positive, not overloaded, disabled.
$D0100000007082<CR> 1000 V, negative, not overloaded, enabled.
SHOW_INTEGRAL [start_chan,number_of_chans]
Reports the sum of the specified group of spectral data channels. If start_chan and
number_of_chans is not provided, SHOW_INTEGRAL reports the sum of all channels in the
currently selected segment that have their ROI flag set.
Responses:
$G0000000000075<CR> Integral reported as 0.
... ...
$G4294967294131<CR> Integral reported as 4294967294.
$G4294967295132<CR> Integral reported as greater than or equal to 4294967295
(maximum reportable value).
SHOW_LENGTH_SAMPLE
Reports the number of points in the InSight Mode Waveform.
Response:
$C00256100 256 points in the waveform.
SHOW_LIVE
Reports the contents of the live-time counter in units of 20 ms (50 ticks/s). See also
CLEAR_COUNTERS and SET_LIVE.
Responses:
$G0000000000075<CR> Live time reported as 0 ticks.
$G0000000001076<CR> Live time reported as 1 tick (20 ms).
... ...
$G4294967295132<CR> Live time reported as 4294967295 ticks (over 23000 days).
SHOW_LIVE_PRES
Reports the current live-time preset in units of 20 ms (50 ticks/s). See also
CLEAR_PRESETS and SET_LIVE_PRESET.
Responses:
$G0000000000075<CR> Live-time preset reported as disabled.
$G0000000001076<CR> Live-time preset reported as 1 tick.
... ...
$G4294967295132<CR> Live-time preset reported as 4294967295 ticks.
SHOW_LLD
Shows the lower level discriminator setting. See also SET_LLD.
37
